Gasonics REL-150-4007电源模块 PDF资料
1.产 品 资 料 介 绍：
产品名称
Gasonics REL-150-4007 电源模块
一、产品概述
REL-150-4007 是一款专用于 Gasonics 等离子清洗设备的四路输出交流转直流电源模块，采用开放式框架设计，提供稳定的多路直流电源，支持设备内部多个模块的用电需求。
二、技术参数
输入电压：85–264V AC
输出电压与电流：
+5V / 15A
+24V / 3A
+15V / 2A
-15V / 2A
最大输出功率：150W
效率：最高约 87%
工作温度范围：0°C 至 +70°C
体积尺寸：约 3.83" x 6.0" x 1.32"
保护功能：具备过压、过流保护
结构特点：开放式框架设计，无风扇冷却
三、应用场景
为 Gasonics 等离子设备的控制模块、传感器、执行器等多模块供电
适合工业自动化设备和医疗设备的多路直流电源需求
用于空间有限的设备内部电源系统
英文资料：
product name
Gasonics REL-150-4007 power module
1、 Product Overview
REL-150-4007 is a four output AC to DC power module specifically designed for Gasonics plasma cleaning equipment. It adopts an open framework design, providing stable multi-channel DC power supply and supporting the power needs of multiple modules inside the equipment.
2、 Technical parameters
Input voltage: 85-264V AC
Output voltage and current:
+5V / 15A
+24V / 3A
+15V / 2A
-15V / 2A
Maximum output power: 150W
Efficiency: up to approximately 87%
Working temperature range: 0 ° C to+70 ° C
Volume size: approximately 3.83 "x 6.0" x 1.32“
Protection function: equipped with overvoltage and overcurrent protection
Structural features: Open frame design, fanless cooling
3、 Application scenarios
Power supply for multiple modules such as control modules, sensors, and actuators of Gasonics plasma equipment
Suitable for multi-channel DC power supply requirements of industrial automation equipment and medical equipment
Internal power supply system for devices with limited space
2.产 品 展 示
