GE IS230PCAAH1A分析 I/O 组件 PDF资料
1.产 品 资 料 介 绍：
产品名称
GE IS230PCAAH1A 分析 I/O 组件
（英文描述：GE Mark VIe I/O Pack – IS230PCAAH1A Analog Input Module）
一、产品概述
IS230PCAAH1A 是 GE Mark VIe 控制系统中使用的 模拟输入 I/O 模块（I/O Pack），用于采集现场的模拟信号并传送至控制器（如 Mark VIe 或 Mark VIeS 系统）。该模块具备高精度、工业级抗干扰能力及系统冗余支持，广泛部署在 GE 的燃气轮机、蒸汽轮机、压缩机及发电厂自动化系统中。
二、技术参数
模块类型：模拟量输入模块（Analog Input I/O Pack）
产品系列：GE Mark VIe / VIeS 控制系统
型号编码：IS230PCAAH1A
输入信号类型：
电流输入（4–20 mA，0–20 mA）
电压输入（±5V、±10V）——取决于 I/O Terminal Board 配置
通道数量：通常 10–20 个模拟输入通道（依连接的终端板类型而定）
通信接口：
与控制器通过 IONet 网络（冗余 Ethernet）通信
I/O Pack 安装在终端板上，通过背板连接信号和电源
电源要求：
来自 I/O Terminal Board 的后备电源供电（一般为 28 VDC）
诊断功能：
通道级短路、断路、自检诊断
通道状态指示 LED
支持冗余：支持与双通道终端板配合实现 I/O 冗余
工作环境：
温度范围：-30°C ~ +65°C
工业环境 EMC 抗干扰设计
适配终端板：兼容多个类型的 I/O Terminal Board（如 TBCA、TBCC）
英文资料：
product name
GE IS230PCAAH1A Analysis of I/O Components
(English description: GE Mark VIe I/O Pack - IS230PCAAH1A Analog Input Module)
1、 Product Overview
IS230PCAAH1A is an analog input I/O module (I/O Pack) used in GE Mark VIe control systems to collect analog signals from the field and transmit them to controllers (such as Mark VIe or Mark VIeS systems). This module has high precision, industrial grade anti-interference capability, and system redundancy support, and is widely deployed in GE's gas turbine, steam turbine, compressor, and power plant automation systems.
2、 Technical parameters
Module type: Analog Input I/O Pack
Product Series: GE Mark VIe/VIeS Control System
Model code: IS230PCAAH1A
Input signal type:
Current input (4-20 mA, 0-20 mA)
Voltage input (± 5V, ± 10V) - depends on the I/O Terminal Board configuration
Number of channels: Typically 10-20 analog input channels (depending on the type of terminal board connected)
Communication interface:
Communicate with the controller through IONet network (redundant Ethernet)
I/O Pack is installed on the terminal board and connects signals and power through the backplane
Power requirements:
Backup power supply from I/O Terminal Board (usually 28 VDC)
Diagnostic function:
Channel level short circuit, open circuit, self check diagnosis
Channel status indicator LED
Support redundancy: Supports I/O redundancy in conjunction with dual channel terminal boards
Work environment:
Temperature range: -30 ° C~+65 ° C
EMC anti-interference design for industrial environment
Compatible with multiple types of I/O Terminal Boards (such as TBCA, TBCC)
2.产 品 展 示
