Gasonics A90-024-02单通道控制板 PDF资料
1.产 品 资 料 介 绍：
产品名称
Gasonics A90-024-02 单通道控制板
产品应用领域
单通道执行器控制
用于 Gasonics 等离子设备中控制一个独立的功能通道，如气体通道、电磁阀、加热单元或机械动作。模块化工艺控制系统
作为模块化控制架构中的单元板卡，通过并列配置多个单通道板，实现多个通道的独立控制与集中管理。信号驱动与反馈监测
处理输入信号（如传感器或上位控制命令），并输出驱动信号至目标设备，同时接收反馈信息用于状态确认。工艺步骤顺序执行
支持工艺中某一步骤的执行触发，如气体注入、阀门开关、组件定位等，配合主控制板实现自动化流程。系统维护与模块替换
用于 Gasonics Aura 系列设备的维修或系统扩展，替换原有损坏或退化的单通道控制模块，保持设备运行稳定。实验设备和定制功能控制
在设备测试或研发环境中，常用于独立控制某一个可调单元，具备灵活的功能分配能力。
英文资料：
product name
Gasonics A90-024-02 Single Channel Control Board
Product application areas
Single channel actuator control
Used to control an independent functional channel in Gasonics plasma equipment, such as gas channels, solenoid valves, heating units, or mechanical actions.
Modular process control system
As a unit board in a modular control architecture, multiple single channel boards are configured in parallel to achieve independent control and centralized management of multiple channels.
Signal driven and feedback monitoring
Process input signals (such as sensors or upper control commands) and output drive signals to the target device, while receiving feedback information for status confirmation.
Sequential execution of process steps
Support the execution triggering of a certain step in the process, such as gas injection, valve switching, component positioning, etc., in conjunction with the main control board to achieve automated processes.
System maintenance and module replacement
Used for maintenance or system expansion of Gasonics Aura series equipment, replacing damaged or degraded single channel control modules to maintain stable equipment operation.
Experimental equipment and customized function control
In equipment testing or development environments, it is commonly used to independently control an adjustable unit with flexible function allocation capabilities.
2.产 品 展 示
