Gasonics A89-014-01显示解码器 PDF资料
1.产 品 资 料 介 绍：
产品名称：Gasonics A89-014-01 显示解码器
部件类型：数字信号解码模块（Digital Signal Decoder Module）
主要功能：将主控系统输出的数字编码信号转换为对应的显示驱动信号，用于控制数码管、LED 显示器等，实现工艺参数和设备状态的可视化
一、设备人机界面显示模块
A89-014-01 常用于 Gasonics 等离子设备的操作面板或控制柜中，负责解码主控板传来的数字信号，驱动显示单元显示工艺进度、报警代码及状态信息。
显示内容示例：
工艺步骤编号
时间倒计时
故障报警代码
设备运行状态指示
二、数字信号转换与驱动
该模块能处理来自主控板的二进制、BCD 或其他编码格式，转换为数码管或 LED 显示的段选和位选信号。
接口类型：
输入数字编码信号（如 BCD）
输出多位数码管驱动信号
三、系统集成应用
作为设备人机交互的重要组成部分，A89-014-01 帮助操作人员直观监测设备状态，便于快速诊断和维护。
常见搭配设备：
主控逻辑板（如 ABX-88919-41-1）
操作控制面板
报警指示模块
英文资料：
Product Name: Gasonics A89-014-01 Display Decoder
Component type: Digital Signal Decoder Module
Main function: Convert the digital encoded signals output by the main control system into corresponding display driving signals for controlling digital tubes, LED displays, etc., to achieve visualization of process parameters and equipment status
1、 Equipment human-machine interface display module
A89-014-01 is commonly used in the operation panel or control cabinet of Gasonics plasma equipment, responsible for decoding digital signals from the main control board, driving the display unit to display process progress, alarm codes, and status information.
Display content example:
Process step number
Time countdown
Fault alarm code
Equipment operation status indication
2、 Digital signal conversion and driving
This module can process binary, BCD, or other encoding formats from the main control board and convert them into segment selection and bit selection signals displayed on digital tubes or LEDs.
Interface type:
Input digital encoded signal (such as BCD)
Output multiple digit digital tube drive signals
3、 System integration application
As an important component of device human-computer interaction, A89-014-01 helps operators visually monitor device status, facilitating quick diagnosis and maintenance.
Common equipment combinations:
Main control logic board (such as ABX-88919-41)
Operator Control Panel
Alarm indication module
