Gasonics A39-1486输入模块 PDF资料
1.产 品 资 料 介 绍：
产品名称：Gasonics A39-1486 输入模块
部件类型：多通道数字输入接口模块（Digital Input Interface Module）
主要功能：接收设备各类数字信号（如开关量、传感器信号），并传递至主控系统进行逻辑处理，实现工艺流程的自动控制与监测
一、信号采集接口
该模块用于采集来自机械开关、传感器、按钮等的数字信号，转换为主控系统能识别的标准信号格式。
典型输入信号：
机械限位开关信号
光电传感器触发信号（如 Gasonics A89-004-01）
设备安全联锁状态
按钮操作信号
二、工艺流程监控关键单元
A39-1486 输入模块实时监测各类工艺状态及设备运行状态，为控制板提供准确的状态反馈，保障工艺安全和稳定。
应用场景：
负载锁门位置检测
升降平台到位确认
真空阀门开关状态监测
故障报警触发信号采集
三、与控制系统的配合
该模块通过标准工业总线或专用接口与 Gasonics 主控板（如 ABX-88919-41-1）连接，实现信号的快速传输和处理。
接口特点：
多通道输入，支持多路开关量信号
信号防抖和滤波设计，提高可靠性
电气隔离保护，保障系统安全
英文资料：
Product Name: Gasonics A39-1486 Input Module
Component type: Multi channel Digital Input Interface Module
Main function: Receive various digital signals from devices (such as switch values and sensor signals) and transmit them to the main control system for logical processing, achieving automatic control and monitoring of the process flow
1、 Signal acquisition interface
This module is used to collect digital signals from mechanical switches, sensors, buttons, etc., and convert them into standard signal formats that can be recognized by the main control system.
Typical input signal:
Mechanical limit switch signal
Photoelectric sensor trigger signal (such as Gasonics A89-004-01)
Equipment safety interlock status
Button operation signal
2、 Key units for process monitoring
The A39-1486 input module monitors various process statuses and equipment operating statuses in real-time, providing accurate status feedback for the control board to ensure process safety and stability.
Application scenarios:
Load lock door position detection
Confirmation of the lifting platform in place
Vacuum valve switch status monitoring
Fault alarm triggering signal acquisition
3、 Coordination with the control system
This module is connected to the Gasonics main control board (such as ABX-88919-41) through a standard industrial bus or dedicated interface to achieve fast signal transmission and processing.
Interface features:
Multi channel input, supporting multiple switch signals
Signal stabilization and filtering design to improve reliability
Electrical isolation protection ensures system safety
2.产 品 展 示
