Gasonics 16321-01 D电源模块 PDF资料
1.产 品 资 料 介 绍：
产品名称：Gasonics 16321-01 D 电源模块
部件类型：直流稳压电源 / 电源供应板（DC Power Supply Module）
主要功能：为 Gasonics 等离子清洗设备中的控制系统、驱动模块和传感器等提供稳定的低压直流电源
一、控制系统核心供电单元
该模块通常安装于 Gasonics 清洗设备（如 Aura 系列、AE 系列）的控制机架中，是设备各类电子控制子系统的主要直流电源来源。
主要输出规格（参考，具体型号需测量确认）：
多通道 DC 输出：如 +5V、+15V、-15V、+24V 等
总功率输出等级：约 100W–200W（视型号而定）
高稳定性与负载响应能力
二、支持模块/设备供电
16321-01 D 模块为多种关键组件提供电力支持：
接口控制面板（如 A95-108-02）
步进驱动器（如 RD-323M10）
光电传感器（如 A89-004-01）
I/O 输出模块（如 A39-1485）
主控逻辑电路板、显示面板、警示灯
三、电气特性与保护功能
该模块具备标准工业电源的稳定输出与保护功能：
过流保护：防止负载短路损坏模块
过压保护：防止电路板损坏
过温保护：防止功率模块内部过热烧毁
抗干扰滤波：适用于射频等离子设备的复杂电磁环境
英文资料：
Product Name: Gasonics 16321-01 D Power Module
Component type: DC stabilized power supply/power supply module
Main function: Provide stable low-voltage DC power supply for control systems, drive modules, sensors, etc. in Gasonics plasma cleaning equipment
1、 Core power supply unit of control system
This module is usually installed in the control rack of Gasonics cleaning equipment (such as Aura series, AE series) and is the main DC power source for various electronic control subsystems of the equipment.
Main output specifications (reference, specific models need to be measured and confirmed):
Multi channel DC output: such as+5V,+15V, -15V,+24V, etc
Total power output level: approximately 100W-200W (depending on the model)
High stability and load response capability
2、 Support module/device power supply
The 16321-01 D module provides power support for various key components:
Interface control panel (such as A95-108-02)
Stepper driver (such as RD-323M10)
Photoelectric sensor (such as A89-004-01)
I/O output module (such as A39-1485)
Main control logic circuit board, display panel, warning light
3、 Electrical characteristics and protection functions
This module has stable output and protection functions of standard industrial power supply:
Overcurrent protection: prevent module damage caused by load short circuit
Overvoltage protection: prevent damage to the circuit board
Over temperature protection: prevent the power module from overheating and burning out internally
Anti interference filtering: suitable for complex electromagnetic environments of RF plasma equipment
