Gasonics 95-0292 MAP130-4000电源供应模块 PDF资料
1.产 品 资 料 介 绍：
产品名称：Gasonics 95-0292 电源供应模块
原始型号：Astec MAP130-4000
部件类型：开关模式电源（Switching Power Supply Module）
主要功能：为 Gasonics 等离子处理设备中的控制系统、驱动器、I/O 模块等提供稳定直流电源
一、设备控制系统主电源
该模块通常安装在 Gasonics 清洗设备（如 Aura 系列、L3500、P5000 等）控制机架中，用于为逻辑控制板、继电器、传感器等低压系统供电。
典型输出电压：
+5V / +12V / -12V DC
功率等级：约 130W 总输出能力
多路隔离输出，满足不同板卡/控制器需求
二、驱动器与信号板电源支持
MAP130-4000 常作为步进电机驱动器（如 RD-323M10）、接口控制面板（如 A95-108-02）等模块的供电来源。
支持设备包括：
控制主板、继电器板
RF 控制器辅助电源
传感器供电（如光电/电容式传感器）
英文资料：
Product Name: Gasonics 95-0292 Power Supply Module
Original model: Astec MAP130-4000
Component type: Switching Power Supply Module
Main function: Provide stable DC power supply for control systems, drivers, I/O modules, etc. in Gasonics plasma processing equipment
1、 Main power supply for equipment control system
This module is typically installed in the control rack of Gasonics cleaning equipment (such as Aura series, L3500, P5000, etc.) to supply power to low-voltage systems such as logic control boards, relays, sensors, etc.
Typical output voltage:
+5V / +12V / -12V DC
Power level: Approximately 130W total output capacity
Multiple isolated outputs to meet the requirements of different boards/controllers
2、 Driver and signal board power support
MAP130-4000 is commonly used as a power source for modules such as stepper motor drivers (such as RD-323M10) and interface control panels (such as A95-108-02).
Supporting devices include:
Control motherboard, relay board
RF controller auxiliary power supply
Sensor power supply (such as photoelectric/capacitive sensors)
2.产 品 展 示
