Gasonics AWD-D-1-0-023-003电源模块 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
Gasonics AWD-D-1-0-023-003 是一款应用于 Gasonics 等离子设备中的 专用电源模块，用于为控制板、接口面板、气体系统驱动单元、传感器等子系统提供稳定的低压直流电源。该模块具备高效率、稳定性强、多路输出等特性，是确保整机电子系统正常运行的核心电源单元之一。
二、应用领域
1. 等离子设备控制系统供电
向主控板、显示驱动器、I/O 接口板等核心板卡提供稳定直流电源（如 +5V、+12V、±15V 等）；
2. 执行与感测单元供电
为电磁阀、升降驱动器、负载锁门控系统、压力传感器等模块供电；
3. 设备稳定运行保障系统
与 UPS 系统或主电源板联动，确保断电保护及电压过载保护。
三、产品优势
高电源效率：采用工业级开关电源方案，支持长时间满载运行；
多通道电压输出：支持多种电压等级同时输出，适应多种模块需求；
抗干扰能力强：EMC 屏蔽良好，适用于高噪声工业环境；
模块化结构设计：便于集成、替换与故障维护；
过压/过流/短路保护：提升设备运行的安全性与可靠性。
英文资料：
1、 Product Overview
Gasonics AWD-D-1-0-023-003 is a dedicated power module used in Gasonics plasma equipment to provide stable low-voltage DC power to subsystems such as control boards, interface panels, gas system drive units, sensors, etc. This module has the characteristics of high efficiency, strong stability, and multiple outputs, and is one of the core power supply units to ensure the normal operation of the entire electronic system.
2、 Application Fields
1. Power supply for plasma equipment control system
Provide stable DC power supply (such as+5V,+12V, ± 15V, etc.) to core boards such as the main control board, display driver, and I/O interface board;
2. Power supply for execution and sensing units
Provide power to modules such as solenoid valves, lift drivers, load lock door control systems, pressure sensors, etc;
3. Equipment stable operation guarantee system
Integrate with UPS system or main power board to ensure power-off protection and voltage overload protection.
3、 Product advantages
High power efficiency: adopting industrial grade switching power supply solution, supporting long-term full load operation;
Multi channel voltage output: supports simultaneous output of multiple voltage levels to meet the needs of multiple modules;
Strong anti-interference ability: Good EMC shielding, suitable for high noise industrial environments;
Modular structure design: easy to integrate, replace, and maintain in case of malfunctions;
Overvoltage/overcurrent/short circuit protection: enhances the safety and reliability of equipment operation.
