ABB 3BHE039203R0101 GVC736CE101可控硅模块 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
GVC736CE101（ABB订货号：3BHE039203R0101）是一款高功率工业级 可控硅模块（Thyristor Module），隶属于ABB电力电子组件系统中的关键控制器件。该模块主要应用于中高压变频驱动、电网换流、电力传动等领域，用于电力控制、换流和整流等功能，是ABB中压驱动系统（如ACS6000/ACS800MV等）的核心部件之一。
二、技术参数（典型值）
| 项目 | 参数值或说明 |
|---|---|
| 型号 | GVC736CE101 |
| 订货号 | 3BHE039203R0101 |
| 类型 | 可控硅模块 / 晶闸管组件 |
| 电压等级（V<sub>drm</sub>） | 4500V 典型（根据规格不同略有变化） |
| 通态平均电流（I<sub>T(AV)</sub>） | 2500A~3000A 典型 |
| 控制方式 | 相控触发或整流/逆变控制 |
| 封装形式 | 工业级模块封装，带冷却接口 |
| 应用系统 | ABB中压驱动、电力传动、电能质量设备 |
| 冷却方式 | 水冷 / 强制风冷 |
三、应用场景
1. ABB中压变频器系统（ACS6000 / ACS800MV）
作为主功率部分的核心整流/换流模块；
适用于高功率工业电机的速度控制、节能运行；
行业：石化、水泥、冶金、矿业等。
2. 高压整流系统
应用于冶金、化工行业中的高压直流整流器；
如：电解铝、电镀、电弧炉供电系统；
提供稳定大电流直流输出。
3. 电网换流站 / HVDC系统
用于交直流电能转换站的换流阀模块；
保证电网电压、电流方向灵活切换；
具备极高的电气可靠性要求。
4. 大型同步电机励磁系统
用于提供可调励磁电流以控制同步电机运行；
在发电厂汽轮机、水轮机驱动系统中常见。
5. FACTS电能质量控制装置
如SVC（静止无功补偿）系统或STATCOM系统中；
提供快速动态响应，平衡电压波动、谐波抑制。
英文资料：
1、 Product Overview
GVC736CE101 (ABB order number: 3BHE039203R0101) is a high-power industrial grade thyristor module (Thyristor Module), which is a key control device in ABB power electronic component systems. This module is mainly used in the fields of medium and high voltage variable frequency drive, grid commutation, power transmission, etc., for functions such as power control, commutation, and rectification. It is one of the core components of ABB medium voltage drive systems (such as ACS6000/ACS800MV, etc.).
2、 Technical parameters (typical values)
Project parameter values or descriptions
Model GVC736CE101
Order number 3BHE039203R0101
Type: thyristor module/thyristor component
Voltage level (V<sub>drm</sub>) 4500V typical (slightly varying depending on specifications)
On state average current (I<sub>T (AV)</sub>) 2500A~3000A typical
Control mode: phase controlled triggering or rectification/inverter control
Packaging form: Industrial grade module packaging with cooling interface
Application system ABB medium voltage drive, power transmission, power quality equipment
Cooling method: Water cooling/forced air cooling
3、 Application scenarios
1. ABB medium voltage frequency converter system (ACS6000/ACS800MV)
As the core rectifier/converter module of the main power section;
Suitable for speed control and energy-saving operation of high-power industrial motors;
Industries: Petrochemicals, Cement, Metallurgy, Mining, etc.
2. High voltage rectification system
High voltage DC rectifiers used in the metallurgical and chemical industries;
For example: electrolytic aluminum, electroplating, electric arc furnace power supply system;
Provide stable high current DC output.
3. Grid converter station/HVDC system
Converter valve module for AC/DC power conversion stations;
Ensure flexible switching of voltage and current directions in the power grid;
Has extremely high electrical reliability requirements.
4. Excitation system for large synchronous motors
Used to provide adjustable excitation current to control the operation of synchronous motors;
Commonly seen in power plant turbine and water turbine drive systems.
5. FACTS power quality control device
Such as SVC (Static Var Compensation) system or STATCOM system;
Provide fast dynamic response, balance voltage fluctuations, and suppress harmonics.
2.产 品 展 示
