3BSE050199R1控制器模块,PM866K02使用说明
硬件配置产生所需的配置并确保MVME2603/2604，您可能需要执行某些硬件安装模块前的修改。MVME2603/2604提供了对大多数选项的软件控制：通过在系统中安装模块后，在控制寄存器中设置位可以修改其配置。（MVME2603/2604控制寄存器为如第3章功能描述和/或MVME2600中所述系列单板计算机程序员参考指南，如中所列附录D，相关文件。）
3BSE050199R1控制器模块然而，有些选项不是软件可编程的。这些选项包括通过手动安装或拆除收割台跳线或基板上的接口模块或相关转换模块VME2603/2604基板准备第1-9页的图1-2说明了开关、跳线的位置MVME2603/2604上的标题、连接器和LED指示灯。基板上可手动配置的项目包括：❏ 缓存模式控制（J3）❏ 闪存组选择（J10）❏ 串行端口4接收时钟配置（J16）❏ 串行端口4传输时钟配置（J17）❏ 串口4发送时钟接收器缓冲控制（J20）❏ 串行端口3传输时钟配置（J18）❏ 系统控制器选择（J22）结合基板上的串行端口设置，串行端口在相关的MVME712M或MVME761过渡模块上可手动配置。用于讨论过渡模块，参见MVME712M过渡模块准备第1-14页，第1-25页MVME761过渡模块准备，或转换模块的相应用户手册（在中列出附录D，相关文件），如有必要。MVME2603/2604经过工厂测试，并随以下各节中描述的配置。这个MVME2603/2604的要求和工厂安装的调试监视器，PPCBug使用这些出厂设置。
Hardware Configuration
To produce the desired configuration and ensure proper operation of the
MVME2603/2604, you may need to carry out certain hardware
modifications before installing the module.
The MVME2603/2604 provides software control over most options: by
setting bits in control registers after installing the module in a system, you
can modify its configuration. (The MVME2603/2604 control registers are
described in Chapter 3, Functional Description, and/or in the MVME2600
Series Single Board Computer Programmer’s Reference Guide, as listed in
Appendix D, Related Documentation.)
Some options, however, are not software-programmable. Such options are
controlled through manual installation or removal of header jumpers or
interface modules on the base board or the associated transition moduleMVME2603/2604 Base Board Preparation
Figure 1-2 on page 1-9 illustrates the placement of the switches, jumper
headers, connectors, and LED indicators on the MVME2603/2604.
Manually configurable items on the base board include:
❏ Cache mode control (J3)
❏ Flash bank selection (J10)
❏ Serial Port 4 receive clock configuration (J16)
❏ Serial Port 4 transmit clock configuration (J17)
❏ Serial Port 4 transmit clock receiver buffer control (J20)
❏ Serial Port 3 transmit clock configuration (J18)
❏ System controller selection (J22)
In conjunction with the serial port settings on the base board, serial ports
on the associated MVME712M or MVME761 transition module are also
manually configurable. For a discussion of the configurable items on the
transition module, refer to MVME712M Transition Module Preparation
on page 1-14, MVME761 Transition Module Preparation on page 1-25, or
to the respective user’s manuals for the transition modules (listed in
Appendix D, Related Documentation) as necessary.
The MVME2603/2604 is factory tested and shipped with the
configurations described in the following sections. The
MVME2603/2604’s required and factory-installed debug monitor,
PPCBug, operates with those factory settings.
