Atlas Copco TC52SM控制器单元 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
TC52SM 是 Atlas Copco 推出的 TC5000 系列控制器中的一款 多通道伺服控制单元，通常配合 Power MACS 4000 或多轴拧紧系统使用。该控制器专为需要高精度、多轴同步控制的工业装配场景而设计，具有紧凑结构、高速数据处理能力以及强大的实时通信能力。
“SM” 一般代表 “Servo Module”，即伺服模块，用于集中控制多个伺服拧紧通道。
二、产品功能与技术参数
型号：TC52SM
类型：伺服驱动控制器单元（多轴控制）
主要用途：集中驱动并控制多通道电动紧固工具
控制支持：
高精度扭矩/角度/速度控制
多通道同步控制
紧固曲线实时监控
通信接口：支持 EtherNet/IP、PROFINET、PROFIBUS 等
程序支持：可配置多个紧固工艺程序，快速切换
电气保护：具备短路、过温、过载等电气防护
安装方式：标准控制柜集成，模块化结构
三、应用领域
1. 汽车制造
发动机、车桥、悬挂系统等多螺栓同步拧紧
高节拍流水线的核心控制单元
适配 Atlas Copco 多轴系统与定制夹具
2. 大型工业设备装配
适用于重型机械设备、机床等结构件紧固
支持高扭矩、长行程同步控制
3. 家电与电子制造
支持多工位柔性切换
提高组装精度与装配效率
4. 轨道交通与航空航天
用于高度一致性要求的螺栓连接
具备全过程数据追溯能力，符合质量管理体系
英文资料：
1、 Product Overview
TC52SM is a multi-channel servo control unit in the TC5000 series controllers launched by Atlas Copco, typically used in conjunction with Power MACS 4000 or multi axis tightening systems. This controller is designed specifically for industrial assembly scenarios that require high-precision, multi axis synchronous control. It has a compact structure, high-speed data processing capabilities, and powerful real-time communication capabilities.
SM "generally represents" Servo Module ", which is used to centrally control multiple servo tightening channels.
2、 Product Features and Technical Parameters
Model: TC52SM
Type: Servo drive controller unit (multi axis control)
Main purpose: Centralized drive and control of multi-channel electric fastening tools
Control support:
High precision torque/angle/speed control
Multi channel synchronous control
Real time monitoring of fastening curves
Communication interface: Supports EtherNet/IP, PROFINET, PROFIBUS, etc
Program support: Multiple fastening process programs can be configured for quick switching
Electrical protection: equipped with electrical protection such as short circuit, over temperature, overload, etc
Installation method: Standard control cabinet integration, modular structure
3、 Application Fields
1. Automobile manufacturing
Synchronized tightening of multiple bolts such as engine, axle, suspension system, etc
The core control unit of high tempo assembly line
Adapt to Atlas Copco multi axis system and custom fixtures
2. Assembly of large industrial equipment
Suitable for fastening structural components of heavy machinery equipment, machine tools, etc
Support high torque and long stroke synchronous control
3. Home appliances and electronic manufacturing
Support flexible switching between multiple workstations
Improve assembly accuracy and efficiency
4. Rail Transit and Aerospace
Bolt connections for high consistency requirements
Having the ability to trace data throughout the entire process, in compliance with the quality management system
2.产 品 展 示
