Atlas Copco TC54S-CC驱动器 PDF资料

1.产 品 资 料 介 绍：

一、产品概述

TC54S-CC 是 Atlas Copco 推出的 伺服驱动器（Servo Drive），隶属于 TC5000 系列产品线。该驱动器主要用于控制多轴电动拧紧系统中的伺服电机，具备高精度、高响应、低延迟的特点。型号中 “CC” 一般表示其通信接口支持 CANopen 或 其他定制通信协议，用于与上位系统如 Power MACS 或 Power Focus 控制器配套使用。

二、技术特点与功能

• 产品型号：TC54S-CC

• 控制方式：精确扭矩、角度与转速控制

• 兼容平台：与 Atlas Copco 多轴拧紧系统兼容（如 Power MACS 4000）

• 通信协议：支持 CC（通常为 CANopen Communication 或 Custom Communication）

• 实时监控：支持拧紧过程数据采集与曲线记录

• 驱动支持：

• 控制伺服工具的动作顺序

• 反馈马达状态（位置、速度、电流）

• 故障自诊断与远程配置

• 安全机制：具备过温、过载、短路等多重保护

三、典型应用领域

1. 汽车制造

• 发动机、变速箱、车架等多工位拧紧工艺

• 多轴联动控制，提高节拍与一致性

• 支持螺栓拧紧质量的全流程追溯

2. 工程机械与重工业

• 高扭矩应用场合，如重型机械装配、焊接夹具锁紧等

• 实现稳定的扭矩输出与高强度螺栓连接

3. 家电和电子装配

• 对多轴协同控制要求较高的小型紧固设备

• 精密控制，防止拧紧过度或损伤产品

4. 航空航天

• 用于飞机部件的精密紧固操作

• 结合伺服系统实现可靠性与可追溯性双重保障

英文资料：

1、 Product Overview

TC54S-CC is a servo drive launched by Atlas Copco, belonging to the TC5000 series product line. This driver is mainly used to control servo motors in multi axis electric tightening systems, and has the characteristics of high precision, high response, and low delay. The "CC" in the model generally indicates that its communication interface supports CANopen or other customized communication protocols, and is used in conjunction with upper level systems such as Power MACS or Power Focus controllers.

2、 Technical features and functions

Product model: TC54S-CC

Control method: precise torque, angle, and speed control

Compatible platform: Compatible with Atlas Copco multi axis tightening system (such as Power MACS 4000)

Communication protocol: Supports CC (usually CANopen Communication or Custom Communication)

Real time monitoring: supports data collection and curve recording during the tightening process

Driver support:

Control the action sequence of servo tools

Feedback motor status (position, speed, current)

Fault self diagnosis and remote configuration

Security mechanism: equipped with multiple protections such as overheating, overload, and short circuit

3、 Typical application areas

1. Automobile manufacturing

Multi station tightening process for engine, gearbox, frame, etc

Multi axis linkage control improves rhythm and consistency

Support full process traceability of bolt tightening quality

2. Construction Machinery and Heavy Industry

High torque applications, such as heavy machinery assembly, welding fixture locking, etc

Realize stable torque output and high-strength bolt connection

3. Home appliances and electronic assembly

Small fastening equipment with high requirements for multi axis collaborative control

Precise control to prevent excessive tightening or damage to the product

4. Aerospace

Precision fastening operation for aircraft components

Combining servo system to achieve dual guarantee of reliability and traceability

2.产      品      展      示
