Atlas Copco PF4002-C-DN-HW控制器 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
ATLAS COPCO PF4002-C-DN-HW 控制器 是 Power Focus 4000 系列中的核心控制单元，配备 DeviceNet（DN）工业总线接口，专用于高精度拧紧过程控制。它可与 Tensor 系列电动拧紧工具（如 Tensor ST、Tensor SL、Tensor DS 等）无缝集成，实现自动化装配过程中的高精度、可追溯、智能化拧紧任务。
二、技术参数（简要）
型号：PF4002-C-DN-HW
支持通信：DeviceNet 接口
适配工具：Tensor 系列智能电动扭矩工具
控制模式：扭矩控制、角度控制、联合控制、多步序列
数据功能：实时数据采集、追溯、报警日志、生产统计
集成能力：支持总线通信、IO控制、远程配置与编程
三、产品应用领域
1. 汽车制造行业
发动机缸体、变速箱、转向系统等部件的精密装配
满足高质量拧紧标准（如 ISO、VDA、QS）
支持多通道工位、自动工具识别与切换
2. 航空航天装备装配
高安全性与高一致性需求的螺栓连接
复杂组件装配，如机翼副结构、控制舵面等
数据可追溯性要求高的生产流程
3. 工业设备与家电制造
电机、电泵、压缩机等设备壳体的精密装配
空调、洗衣机等大型家电产品的标准化拧紧工艺控制
支持柔性装配工位与批量管理
4. 电力与能源行业
风电设备、开关柜等大型设备的结构连接
高强度、高负荷工况下的精密螺栓连接
满足长时间运行与过程稳定性要求
5. 工程机械与重工制造
高扭矩场景下（如液压系统、车架）多通道同步拧紧
实现数据记录与异常报警功能，提高生产效率
在多工位装配线中作为主控制单元运行
英文资料：
1、 Product Overview
The ATLAS COPCO PF4002-C-DN-HW controller is the core control unit in the Power Focus 4000 series, equipped with DeviceNet (DN) industrial bus interface, dedicated to high-precision tightening process control. It can be seamlessly integrated with Tensor series electric tightening tools (such as Tensor ST, Tensor SL, Tensor DS, etc.) to achieve high-precision, traceable, and intelligent tightening tasks in automated assembly processes.
2、 Technical parameters (brief)
Model: PF4002-C-DN-HW
Support communication: DeviceNet interface
Adaptation tool: Tensor series intelligent electric torque tool
Control modes: torque control, angle control, joint control, multi-step sequence
Data function: real-time data collection, traceability, alarm logs, production statistics
Integration capability: Supports bus communication, IO control, remote configuration, and programming
3、 Product application areas
1. Automotive manufacturing industry
Precision assembly of engine cylinder block, gearbox, steering system and other components
Meet high-quality tightening standards (such as ISO, VDA, QS)
Support multi-channel workstations, automatic tool recognition and switching
2. Aerospace equipment assembly
Bolt connections with high safety and consistency requirements
Complex component assembly, such as wing substructures, control surfaces, etc
Production processes with high requirements for data traceability
3. Industrial equipment and home appliance manufacturing
Precision assembly of equipment casings such as motors, electric pumps, compressors, etc
Standardized tightening process control for large household appliances such as air conditioners and washing machines
Support flexible assembly stations and batch management
4. Power and energy industry
Structural connections of large equipment such as wind power equipment and switchgear
Precision bolted connections under high-strength and high load conditions
Meet the requirements of long-term operation and process stability
5. Construction Machinery and Heavy Industry Manufacturing
Multi channel synchronous tightening in high torque scenarios (such as hydraulic systems, frames)
Implement data recording and abnormal alarm functions to improve production efficiency
Operate as the main control unit in a multi station assembly line
2.产 品 展 示
