Atlas Copco PF-3110S-S4/7扭矩工具控制器 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
ATLAS COPCO PF-3110S-S4/7 是 Power Focus 3000 系列中的专用拧紧控制器，专为配合 Tensor S4 与 S7 电动扭矩工具而设计。该控制器支持多种工业通信协议，并具备精确的拧紧过程控制、数据记录和过程追溯功能。
二、技术参数（部分特性）
控制器型号：PF-3110S-S4/7（部件号：8433 1700 05）
支持工具：Atlas Copco Tensor S4、Tensor S7 系列
拧紧方式：扭矩控制、角度控制、组合控制
通信接口：以太网、RS-232、RS-485（具体型号支持不同）
数据功能：可追溯数据存储、批次统计、故障报警
软件支持：兼容 ToolsTalk 等工艺管理软件
电源要求：通常为24V DC供电（依实际配置）
三、应用领域
汽车制造
适用于底盘、动力总成、悬挂等部件的关键拧紧
多步骤拧紧序列控制和工艺一致性保证
航空航天
精密部件连接，确保力矩一致性和安全性
工艺过程完全可追溯，满足质量管理需求
电子与电气设备装配
控制板、终端箱等产品的标准化紧固作业
避免过扭和损坏精密组件
通用工业机械
泵体、阀门、液压系统等关键部位的高强度螺栓拧紧
支持大量数据反馈和故障分析
工程机械与重工业
多功能装配工位中对大型紧固件进行高精度控制
英文资料：
1、 Product Overview
ATLAS COPCO PF-3110S-S4/7 is a specialized tightening controller in the Power Focus 3000 series, designed specifically for use with Tensor S4 and S7 electric torque tools. This controller supports multiple industrial communication protocols and has precise tightening process control, data recording, and process traceability functions.
2、 Technical parameters (partial characteristics)
Controller model: PF-3110S-S4/7 (part number: 8433 1700 05)
Supporting tools: Atlas Copco Tensor S4, Tensor S7 series
Tightening method: torque control, angle control, combination control
Communication interfaces: Ethernet, RS-232, RS-485 (specific models supported)
Data function: traceable data storage, batch statistics, fault alarm
Software support: Compatible with ToolsTalk and other process management software
Power requirement: Typically powered by 24V DC (depending on actual configuration)
3、 Application Fields
automobile making
Key tightening for chassis, powertrain, suspension and other components
Multi step tightening sequence control and process consistency assurance
EADS
Precise component connection ensures torque consistency and safety
The process is fully traceable and meets the requirements of quality management
Assembly of electronic and electrical equipment
Standardized fastening operations for control boards, terminal boxes, and other products
Avoid excessive twisting and damage to precision components
General industrial machinery
Tightening high-strength bolts on key parts such as pump body, valves, hydraulic system, etc
Support a large amount of data feedback and fault analysis
Construction Machinery and Heavy Industry
High precision control of large fasteners in multifunctional assembly stations
2.产 品 展 示
