Atlas Copco TC52P-N4240041 080组装系统控制器 PDF资料
1.产 品 资 料 介 绍：
一、产品简介
ATLAS COPCO TC52P-N4240041 080 是一款用于工业自动化装配领域的伺服拧紧控制器，属于 Atlas Copco TC52 系列。该型号设计用于精确控制拧紧过程中的扭矩、角度与时间，是高性能装配线（如汽车、工程机械、电子产品）的核心控制设备之一。
其强大的数据处理能力、开放通信接口和模块化设计，使其特别适合多工具、多工艺工位的装配场景，支持全流程拧紧控制与质量追溯。
二、主要技术特点
型号全称：TC52P-N4240041 080
控制类型：伺服拧紧控制器
适配工具：兼容 Tensor ST、STB、STR 等系列伺服工具
控制方式：闭环扭矩 + 角度 + 过程段位控制
支持通道：多轴控制能力，适合复杂同步装配
通信接口：
Ethernet/IP
PROFINET
CANopen、DeviceNet 等多种总线协议
高级功能：
多任务程序管理
快速切换工艺
实时曲线监控
错误诊断与报警系统
数据采集与历史追溯（支持 MES 接入）
三、典型应用场景
| 行业 | 应用实例 |
|---|---|
| 汽车制造 | 发动机、底盘、悬挂系统装配 |
| 工业设备 | 重载结构件紧固、多螺栓同步控制 |
| 电子与家电 | 高节拍小扭矩自动化装配 |
| 航空航天 | 高安全级别紧固件质量控制 |
| 轨道交通 | 结构件安装与质量追溯 |
英文资料：
Brief introduction
ATLAS COPCO TC52P-N4240041 080 is a servo tightening controller used in the field of industrial automation assembly, belonging to the Atlas Copco TC52 series. This model is designed for precise control of torque, angle, and time during the tightening process, and is one of the core control devices for high-performance assembly lines such as automobiles, construction machinery, and electronic products.
Its powerful data processing capabilities, open communication interfaces, and modular design make it particularly suitable for assembly scenarios with multiple tools and process stations, supporting full process tightening control and quality traceability.
2、 Main technical features
Model name: TC52P-N4240041 080
Control type: servo tightening controller
Adaptation tool: compatible with Tensor ST, STB, STR and other series of servo tools
Control method: closed-loop torque+angle+process stage control
Support channel: Multi axis control capability, suitable for complex synchronous assembly
Communication interface:
Ethernet/IP
PROFINET
Multiple bus protocols such as CANopen and DeviceNet
Advanced features:
Multi tasking program management
Quickly switch processes
Real time curve monitoring
Error diagnosis and alarm system
Data collection and historical tracing (supporting MES access)
3、 Typical application scenarios
Industry application examples
Automobile manufacturing engine, chassis, suspension system assembly
Tightening of heavy-duty structural components in industrial equipment and synchronous control of multiple bolts
Electronic and home appliance high cycle small torque automated assembly
Quality Control of High Safety Fasteners in Aerospace Industry
Installation and Quality Traceability of Rail Transit Structural Components
2.产 品 展 示
