Atlas Copco PF3109-G-DN-HW处理器 PDF资料
1.产 品 资 料 介 绍：
产品名称
Atlas Copco PF3109-G-DN-HW 处理器
（Power Focus 3100 系列高性能智能拧紧控制器）
产品概述
PF3109-G-DN-HW 是 Atlas Copco Power Focus 3100 系列中的高性能智能拧紧控制器，集成高级处理能力和多功能通信接口。
G 表示高级功能版本，带图形用户界面支持
DN 表示内置 DeviceNet 通信接口，便于工业现场网络连接
HW 表示标准硬件版本
该处理器主要用于控制和驱动 Tensor 系列中高扭矩电动拧紧工具，实现多阶段扭矩与角度控制，支持实时数据采集和过程质量监控。
主要应用领域
汽车制造及总装
发动机、底盘、转向系统及车身结构的精密螺栓拧紧
支持工位级程序切换及 MES 系统数据上传，确保装配质量和过程追溯
新能源汽车与动力电池装配
电池模组、电控箱及电驱系统的关键连接拧紧
防止漏拧、过拧，满足高可靠性装配工艺需求
工业机器人拧紧工作站
机器人自动化装配线中的智能扭矩控制
多程序管理及复杂工艺流程支持
工程机械及轨道交通装备制造
大型结构件及关键连接部位的高精度拧紧控制
远程监控及质量数据采集，保障长期稳定运行
家电及电子产品制造
多品种、小批量混线生产中的快速程序切换
实时过程控制与数据追踪，提升产品一致性
英文资料：
product name
Atlas Copco PF3109-G-DN-HW processor
(Power Focus 3100 series high-performance intelligent tightening controller)
product overview
PF3109-G-DN-HW is a high-performance intelligent tightening controller in the Atlas Copco Power Focus 3100 series, integrating advanced processing capabilities and multifunctional communication interfaces.
G represents the advanced feature version with graphical user interface support
DN stands for built-in DeviceNet communication interface, which facilitates network connection in industrial sites
HW represents the standard hardware version
This processor is mainly used to control and drive high torque electric tightening tools in the Tensor series, achieving multi-stage torque and angle control, supporting real-time data acquisition and process quality monitoring.
Main application areas
Automobile manufacturing and final assembly
Precision bolt tightening for engine, chassis, steering system, and body structure
Support workstation level program switching and MES system data uploading to ensure assembly quality and process traceability
Assembly of new energy vehicles and power batteries
Tightening of key connections between battery modules, electrical control boxes, and electric drive systems
Prevent missing or over twisting to meet the high reliability assembly process requirements
Industrial Robot Tightening Workstation
Intelligent torque control in robot automated assembly line
Multi program management and support for complex process flows
Manufacturing of engineering machinery and rail transit equipment
High precision tightening control of large structural components and key connecting parts
Remote monitoring and quality data collection to ensure long-term stable operation
Manufacturing of household appliances and electronic products
Fast program switching in multi variety and small batch mixed line production
Real time process control and data tracking to enhance product consistency
