Atlas Copco PF3109-G-DN-H控制器 PDF资料
1.产 品 资 料 介 绍：
产品名称
Atlas Copco PF3109-G-DN-H 控制器
（Power Focus 3100 系列高性能智能拧紧控制器）
产品概述
PF3109-G-DN-H 是 Atlas Copco Power Focus 3100 系列中高功率、高性能版本的智能控制器。
G 表示具备高级功能和图形界面支持
DN 表示内置 DeviceNet 通信接口
H 表示硬件升级版，具备更高稳定性和扩展性
该控制器用于驱动和控制 Tensor 系列电动拧紧工具，支持复杂的多阶段拧紧策略和实时数据监控，满足高要求工业装配线的应用。
主要应用领域
汽车制造及装配
发动机、底盘、车身结构、转向及悬挂系统的螺栓精密拧紧
工位级程序切换和 MES 系统数据集成，实现质量追溯和防错管理
新能源汽车与动力电池行业
电池模组、电驱壳体、电控单元的可靠拧紧
确保连接强度和过程可控，防止漏拧、滑牙
工业机器人自动化装配线
机器人拧紧工作站控制，支持复杂的多程序管理
与主控 PLC 和机器人控制系统无缝通信
工程机械、轨道交通等重载设备制造
大型结构件的关键螺栓连接控制
支持远程监控和数据追踪，满足高可靠性需求
家电及电子产品装配
快速切换多品种柔性生产线中的螺栓紧固作业
实时监控扭矩与角度，保证产品质量
英文资料：
product name
Atlas Copco PF3109-G-DN-H Controller
(Power Focus 3100 series high-performance intelligent tightening controller)
product overview
PF3109-G-DN-H is a high-power, high-performance version of the Atlas Copco Power Focus 3100 series intelligent controller.
G represents advanced functionality and graphical interface support
DN stands for built-in DeviceNet communication interface
H represents a hardware upgrade version with higher stability and scalability
This controller is used to drive and control Tensor series electric tightening tools, supporting complex multi-stage tightening strategies and real-time data monitoring, meeting the requirements of high demand industrial assembly line applications.
Main application areas
Automobile manufacturing and assembly
Precise tightening of bolts for engine, chassis, body structure, steering, and suspension systems
Workstation level program switching and MES system data integration to achieve quality traceability and error prevention management
New energy vehicles and power battery industry
Reliable tightening of battery modules, electric drive housings, and electronic control units
Ensure connection strength and controllable process to prevent missing or slipping teeth
Industrial robot automated assembly line
Robot tightening workstation control, supporting complex multi program management
Seamless communication with the main control PLC and robot control system
Manufacturing of heavy-duty equipment such as construction machinery and rail transit
Key bolt connection control of large structural components
Support remote monitoring and data tracking to meet high reliability requirements
Assembly of household appliances and electronic products
Quickly switch bolt tightening operations in flexible production lines with multiple varieties
Real time monitoring of torque and angle to ensure product quality
