Atlas Copco PF3107-C-HW变频器 PDF资料
1.产 品 资 料 介 绍：
产品名称：Atlas Copco PF3107-C-HW 智能拧紧控制器
产品类型：Power Focus 3100 系列控制单元
功能定位：驱动和控制 Atlas Copco 电动拧紧工具，实现高精度扭矩/角度控制及全过程质量追溯
主要应用领域：
汽车制造
发动机、变速箱、底盘、车身结构等关键部位的螺栓连接
支持工位识别、程序切换、MES 数据上传
新能源汽车与电池装配
动力电池模组、电驱、电控壳体拧紧
满足扭矩一致性、连接安全性和整车数据追溯要求
工业自动化与机器人集成
用于机器人自动拧紧站、柔性装配单元
可通过 PROFIBUS、PROFINET、EtherNet/IP 等通讯协议与 PLC 或主系统对接
家电与电气产品制造
适用于电机、电控箱、壳体等零部件螺栓拧紧
支持快速换线和多产品混线生产
工程机械与轨道交通设备制造
应用于中扭矩段结构件、法兰件装配
满足高可靠性和工业级过程控制需求
特点总结：
适配中等扭矩工具，控制精度高
支持多段拧紧策略、反扭检测、滑牙识别等防错机制
数据可追溯，支持联网与上位系统集成
可与多种工业总线协议通信，便于接入自动化产线
英文资料：
Product Name: Atlas Copco PF3107-C-HW Intelligent Tightening Controller
Product type: Power Focus 3100 series control unit
Function positioning: Drive and control Atlas Copco electric tightening tool, achieve high-precision torque/angle control and full process quality traceability
Main application areas:
automobile making
Bolt connections of key parts such as engine, gearbox, chassis, and body structure
Support workstation recognition, program switching, MES data upload
New energy vehicles and battery assembly
Tightening of power battery module, electric drive, and electronic control housing
Meet the requirements of torque consistency, connection safety, and vehicle data traceability
Industrial Automation and Robot Integration
Used for robot automatic tightening stations and flexible assembly units
Can be connected to PLC or main system through communication protocols such as PROFIBUS, PROFINET, EtherNet/IP, etc
Manufacturing of household appliances and electrical products
Suitable for tightening bolts on components such as motors, electrical control boxes, and casings
Support rapid line switching and mixed production of multiple products
Manufacturing of Engineering Machinery and Rail Transit Equipment
Applied to the assembly of structural components and flange components in the medium torque range
Meet high reliability and industrial grade process control requirements
Summary of Characteristics:
Suitable for medium torque tools with high control accuracy
Support error prevention mechanisms such as multi-stage tightening strategy, anti twist detection, and slip tooth recognition
Data traceability, supporting networking and upper system integration
Can communicate with multiple industrial bus protocols for easy access to automated production lines
2.产 品 展 示
