Atlas Copco PF3007-C-PB-HW驱动器 PDF资料

1.产 品 资 料 介 绍：

一、产品概述

Atlas Copco PF3007-C-PB-HW 是 Power Focus 3000 系列中的一款智能电动工具驱动器（控制器），专为中小扭矩段的电动拧紧工具（如 Tensor ST、STR、EBL 等）提供精密驱动与拧紧过程控制。该控制器内置 PROFIBUS（PB） 通信接口，便于集成到西门子等工业自动化系统中。

型号解析：

• PF3007：表示 3000 系列中 07 型号，支持中等功率等级的工具

• C：标准控制功能，适配通用拧紧任务

• PB：集成 PROFIBUS 通信协议接口

• HW：标准硬件配置

二、关键功能

• 支持 扭矩控制 / 角度控制 / 多段拧紧 / 自适应控制 / 校准补偿

• 与 Tensor ST、SL、STR、ETX、EBL 等工具兼容

• 集成 PROFIBUS DP 接口，方便连接西门子 S7 等控制系统

• 支持拧紧过程监控与错误识别（如滑牙、欠扭、反转等）

• 本地数据记录、实时上传，支持与 MES 系统对接

三、典型应用领域

1. 汽车制造与动力总成装配

• 发动机缸体、油底壳、变速箱壳体、底盘部件等的精密装配

• 多工位并行控制，提升生产节拍和拧紧一致性

2. 新能源汽车（EV）与电池包装配

• 电池壳体、电控系统、电驱总成的精密螺栓连接

• MES 对接拧紧结果绑定 VIN 码，支持条码识别、工位识别

3. 家电与电气设备制造

• 电机、电器壳体、压缩机等结构连接中的批量扭矩控制

• 快速工位切换与多程序拧紧，适应混线生产

4. 机器人拧紧单元

• 与六轴或 SCARA 机器人集成，执行自动拧紧任务

• 控制器安装在机器人臂端或控制柜内，支持远程管理

5. 工程机械、风电、轨道交通

• 大型结构件的中等负载连接，如导轨、座舱、舱门等

• 支持批次管理、数据追溯、故障报警

英文资料：

1、 Product Overview

Atlas Copco PF3007-C-PB-HW is an intelligent electric tool driver (controller) in the Power Focus 3000 series, designed to provide precision drive and tightening process control for electric tightening tools in small and medium torque ranges (such as Tensor ST, STR, EBL, etc.). The controller has a built-in PROFIBUS (PB) communication interface, making it easy to integrate into industrial automation systems such as Siemens.

Model analysis:

PF3007: Refers to the 07 model in the 3000 series, supporting tools with medium power levels

C: Standard control function, compatible with universal tightening tasks

PB: Integrated PROFIBUS communication protocol interface

HW: Standard hardware configuration

2、 Key functions

Support torque control/angle control/multi-stage tightening/adaptive control/calibration compensation

Compatible with tools such as Tensor ST, SL, STR, ETX, EBL, etc

Integrated PROFIBUS DP interface for easy connection to control systems such as Siemens S7

Support tightening process monitoring and error recognition (such as slipping, under twisting, reverse, etc.)

Local data recording and real-time uploading, supporting integration with MES system

3、 Typical application areas

1. Automotive manufacturing and powertrain assembly

Precision assembly of engine cylinder block, oil pan, gearbox housing, chassis components, etc

Multi station parallel control improves production pace and tightening consistency

2. New energy vehicles (EVs) and battery packaging matching

Precision bolt connections for battery casing, electronic control system, and electric drive assembly

MES docking tightening result binding VIN code, supporting barcode recognition and workstation recognition

3. Manufacturing of household appliances and electrical equipment

Batch torque control in structural connections such as motors, electrical casings, compressors, etc

Fast workstation switching and multi program tightening, suitable for mixed line production

4. Robot tightening unit

Integrate with six axis or SCARA robots to perform automatic tightening tasks

The controller is installed at the end of the robot arm or inside the control cabinet and supports remote management

5. Construction machinery, wind power, and rail transit

Medium load connections for large structural components such as rails, cabins, doors, etc

Support batch management, data traceability, and fault alarm

2.产      品      展      示
