Atlas Copco PF4002-G-PB-HW驱动器 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
Atlas Copco PF4002-G-PB-HW 是 Power Focus 4000 系列中的高性能智能拧紧控制器，集驱动、电源、控制和通信功能于一体。该控制器用于管理 Atlas Copco Tensor 系列电动工具，支持高级拧紧逻辑、数据追溯及工业通信集成，适用于高要求的自动化装配环境。
型号含义：
PF4002：4000系列，2级功率控制范围（适配中小扭矩工具）
G：高级版本，支持扩展功能和图形化控制
PB：集成 PROFIBUS 通讯接口
HW：硬件标准版本
二、技术参数（核心摘要）
控制方式：扭矩控制、角度控制、角度监控、多阶段复合控制
适配工具：Tensor STR、STB、EBL、ETX 等 Atlas Copco 系列
支持程序数：最多 999 个独立拧紧程序
通信接口：PROFIBUS、Ethernet、USB、RS232、I/O（可选扩展）
数据功能：拧紧数据采集、存储、分析、实时上传至 MES
安装方式：控制柜内安装或嵌入式设备面板安装
扩展支持：支持 Tool Location、Focus Control、Barcode/RFID 工件识别功能
三、应用领域
1. 汽车与新能源汽车制造
发动机总成、底盘、悬挂、电池模组等高精度拧紧工艺控制
支持与 MES 系统数据对接，实现拧紧任务与 VIN 绑定、工位识别、图形控制流程
2. 工业自动化产线
用于机器人拧紧系统、工作站式拧紧台、多工位协作控制系统
适合柔性生产线中多个产品混线生产、自动程序切换
3. 轨道交通与重型机械
大型结构件、轮对、铰链等高强度连接件的过程控制
可应对高工作负载、高稳定性要求的复杂工况
4. 家电与电子制造
中小扭矩紧固场景，如电机壳体、面板组装、支架连接等
快速工位切换、可视化状态反馈、程序可灵活调度
英文资料：
1、 Product Overview
Atlas Copco PF4002-G-PB-HW is a high-performance intelligent tightening controller in the Power Focus 4000 series, integrating drive, power, control, and communication functions. This controller is used to manage Atlas Copco Tensor series power tools, supporting advanced tightening logic, data traceability, and industrial communication integration, and is suitable for high demand automated assembly environments.
Model meaning:
PF4002:4000 series, 2-level power control range (suitable for small and medium-sized torque tools)
G: Advanced version, supporting extended functionality and graphical control
PB: Integrated PROFIBUS communication interface
HW: Hardware Standard Version
2、 Technical Parameters (Core Summary)
Control methods: torque control, angle control, angle monitoring, multi-stage composite control
Adaptation tools: Atlas Copco series including Tensor STR, STB, EBL, ETX, etc
Number of supported programs: up to 999 independent tightening programs
Communication interfaces: PROFIBUS, Ethernet, USB, RS232, I/O (optional expansion)
Data function: Tighten data collection, storage, analysis, and real-time upload to MES
Installation method: Installation inside the control cabinet or embedded equipment panel installation
Extended support: Supports Tool Location, Focus Control, Barcode/RFID workpiece recognition functions
3、 Application Fields
1. Manufacturing of automobiles and new energy vehicles
High precision tightening process control for engine assembly, chassis, suspension, battery module, etc
Support data integration with MES system to achieve tightening task and VIN binding, workstation recognition, and graphic control process
2. Industrial automation production line
Used for robot tightening systems, workstation style tightening tables, and multi station collaborative control systems
Suitable for mixed production of multiple products and automatic program switching in flexible production lines
3. Rail transit and heavy machinery
Process control of high-strength connectors such as large structural components, wheelsets, hinges, etc
Capable of handling complex working conditions with high workloads and high stability requirements
4. Home appliances and electronics manufacturing
Small and medium-sized torque tightening scenarios, such as motor housing, panel assembly, bracket connections, etc
Fast workstation switching, visual status feedback, and flexible program scheduling
