Atlas Copco PF3007-G-DN-HW控制器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
一、产品概述
Atlas Copco PF3007-G-DN-HW 是 PF3000 系列中的一款功能增强型 工业拧紧控制器，配备 DeviceNet（DN）通信接口，专为中等规模装配线和自动化工作站设计。该型号适用于控制 Atlas Copco 的 Tensor 系列电动工具，实现精确的扭矩、角度控制与数据追溯，是智能制造环境中的关键执行单元之一。
二、技术参数（简要）
控制方式：扭矩控制、角度控制、多阶段复合拧紧
支持通信协议：DeviceNet（硬件集成）、Ethernet、RS232、I/O
兼容工具：Tensor ST、ES、ETX 等系列电动工具
拧紧程序容量：可存储多个拧紧程序，便于多品种作业切换
人机交互：支持通过 ToolsTalk PF 软件设置和监控
安装方式：标准工业安装结构，适用于控制柜或工作站集成
三、应用领域
1. 汽车与新能源汽车装配
适用于发动机、变速箱、底盘系统、座椅框架等关键连接的装配
支持与整车装配MES系统或PLC系统通过 DeviceNet 协议对接，实现工位间自动化联动
新能源汽车动力电池、电控盒、电驱总成的螺栓精密拧紧
2. 轨道交通与重型设备
用于车体、悬挂、制动部件的中高扭矩拧紧控制
工程机械的液压缸、连接板、电机安装工序
3. 工业自动化与机器人装配
工业机器人关节、电控柜、机身结构的拧紧任务
自动化产线拧紧单元的标准控制平台
4. 电子与电器制造
家用电器、电动工具等装配线上的塑料件和金属件固定螺栓控制
精密零部件（如电控模块、传感器外壳）小扭矩螺丝拧紧
5. 智能制造集成场景
与 DeviceNet 总线系统集成，实现多控制器、多工位联动控制
数据实时采集、反馈、质量追溯，支持工业 4.0 要求的透明装配
英文资料：
1、 Product Overview
Atlas Copco PF3007-G-DN-HW is a functional enhanced industrial tightening controller in the PF3000 series, equipped with DeviceNet (DN) communication interface, designed specifically for medium-sized assembly lines and automation workstations. This model is suitable for controlling the Tensor series power tools of Atlas Copco, achieving precise torque and angle control and data traceability. It is one of the key execution units in intelligent manufacturing environments.
2、 Technical parameters (brief)
Control methods: torque control, angle control, multi-stage compound tightening
Supporting communication protocols: DeviceNet (hardware integration) Ethernet、RS232、I/O
Compatible tools: Tensor ST, ES, ETX and other series of power tools
Tightening program capacity: can store multiple tightening programs, making it easy to switch between multiple types of operations
Human computer interaction: supports setting and monitoring through ToolsTalk PF software
Installation method: Standard industrial installation structure, suitable for control cabinet or workstation integration
3、 Application Fields
1. Assembly of automobiles and new energy vehicles
Suitable for assembly of key connections such as engines, transmissions, chassis systems, seat frames, etc
Support integration with vehicle assembly MES system or PLC system through DeviceNet protocol to achieve automated linkage between workstations
Precision tightening of bolts for new energy vehicle power batteries, electronic control boxes, and electric drive assemblies
2. Rail transit and heavy equipment
Medium to high torque tightening control for vehicle body, suspension, and braking components
Installation process of hydraulic cylinders, connecting plates, and motors for construction machinery
3. Industrial automation and robot assembly
Tightening tasks for industrial robot joints, electrical control cabinets, and body structures
Standard control platform for tightening units in automated production lines
4. Electronic and Electrical Manufacturing
Control of fixing bolts for plastic and metal parts on assembly lines of household appliances, power tools, etc
Tighten small torque screws on precision components such as electronic control modules and sensor housings
5. Integrated scenarios for intelligent manufacturing
Integrate with DeviceNet bus system to achieve multi controller and multi station linkage control
Real time data collection, feedback, quality traceability, supporting transparent assembly required by Industry 4.0
2.产 品 展 示
