Atlas Copco PF3007-G-PB-HW处理器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
产品名称：
Atlas Copco PF3007-G-PB-HW 处理器
（Power Focus 3000 系列）
产品概述：
PF3007-G-PB-HW 是 Atlas Copco Power Focus 3000 系列中的控制处理器，用于精确控制电动工具的拧紧过程，适用于中小规模装配生产线。该处理器通过连接电动拧紧工具，实现对扭矩、角度等参数的控制与数据管理，并支持与自动化系统的集成。
型号说明：
PF3007：Power Focus 3000 单工具控制型号
G：通用型（General）控制功能
PB：内置 Profibus 通信协议接口
HW：硬件激活版本（功能通过硬件模块授权）
主要功能：
控制一把 Atlas Copco 电动工具
支持扭矩、角度等多种拧紧策略
本地参数设置与保存
过程数据采集与追溯
报警、容错与过程监控功能
通信能力：
Profibus 工业总线接口（用于连接 PLC）
USB、串口、以太网（可选）
支持 Open Protocol（标准化数据接口）
应用场景：
汽车零部件装配工位
家用电器制造
电气控制柜、终端产品装配
紧凑型或独立工位的拧紧控制
自动化或半自动化生产线
英文资料：
Product Name:
Atlas Copco PF3007-G-PB-HW processor
(Power Focus 3000 Series)
Product Overview:
PF3007-G-PB-HW is a control processor in the Atlas Copco Power Focus 3000 series, used for precise control of the tightening process of power tools and suitable for small and medium-sized assembly production lines. This processor controls and manages parameters such as torque and angle by connecting to an electric tightening tool, and supports integration with automation systems.
Model Description:
PF3007: Power Focus 3000 Single Tool Control Model
G: General control function
PB: Built in Profibus communication protocol interface
HW: Hardware activated version (functions authorized through hardware modules)
Main functions:
Control an Atlas Copco power tool
Support multiple tightening strategies such as torque and angle
Local parameter setting and saving
Process data collection and traceability
Alarm, fault tolerance, and process monitoring functions
Communication ability:
Profibus industrial bus interface (for connecting PLC)
USB、 Serial port, Ethernet (optional)
Support Open Protocol (Standardized Data Interface)
Application scenarios:
Automotive parts assembly station
Manufacturing of household appliances
Electrical control cabinet and terminal product assembly
Tightening control for compact or independent workstations
Automated or semi automated production lines
2.产 品 展 示
