KEBA E-HSI-RS485电路板 PDF资料

1.产 品 资 料 介 绍：

中文资料：

KEBA E-HSI-RS485 是一款专为 KEBA 自动化系统设计的 RS-485 通信接口电路板，用于在工业环境中实现可靠的串行数据通信。它支持基于 RS-485 标准的多点通信，常被用于设备间的数据交互，如传感器、执行器、变频器、PLC 或外部控制设备。该模块适用于 KEBA KeControl 系列中的 HSI（High-Speed Interface）扩展功能板卡，是系统中连接外设的关键通信部件之一。

技术参数

• 产品型号：E-HSI-RS485

• 功能类型：RS-485 通信扩展电路板

• 通信协议：支持标准 RS-485 半双工通信

• 通信速率：最高支持至 1 Mbps（根据线路长度而定）

• 接口形式：

• 端子排或插针式接口（根据系统集成方式）

• 可能支持可配置终端电阻

• 绝缘保护：带光电隔离，提升电气安全性

• 安装方式：模块化插装至主控系统插槽或连接背板

• 供电要求：由主系统提供 5V 或 24V（依内部电源架构）

• 兼容平台：KEBA KeControl / KePlast / KeMotion 等系统平台

应用场景

1. 注塑机或挤出机通信接口扩展

• 用于连接外部温控模块、称重系统或分布式控制节点

• 多点通信能力支持复杂设备间联动

2. 变频器或伺服驱动器通信

• 通过 RS-485 实现对第三方驱动设备的参数读写

• 支持 MODBUS RTU 等工业通信协议

3. 现场总线通讯

• 连接传感器、仪表、操作面板等使用 RS-485 接口的设备

• 构建多主多从的控制结构

4. 工业组网与远距离通信

• 在工厂环境中进行稳定的远程设备串行通信（最长可达 1200 米）

• 提高自动化系统的扩展能力

英文资料：

KEBA E-HSI-RS485 is an RS-485 communication interface circuit board designed specifically for KEBA automation systems, used to achieve reliable serial data communication in industrial environments. It supports multi-point communication based on the RS-485 standard and is often used for data exchange between devices such as sensors, actuators, frequency converters, PLCs, or external control devices. This module is suitable for the HSI (High Speed Interface) expansion function board in the KEBA KeControl series and is one of the key communication components for connecting peripherals in the system.

Technical Parameter

Product model: E-HSI-RS485

Function type: RS-485 communication expansion circuit board

Communication protocol: Supports standard RS-485 half duplex communication

Communication speed: Supports up to 1 Mbps (depending on line length)

Interface form:

Terminal block or plug-in interface (depending on the system integration method)

May support configurable terminal resistors

Insulation protection: equipped with photoelectric isolation to enhance electrical safety

Installation method: Modular insertion into the main control system slot or connection to the backplane

Power supply requirements: 5V or 24V provided by the main system (depending on the internal power architecture)

Compatible platforms: KEBA KeControl/KePlast/KeMotion and other system platforms

Application scenarios

Expansion of communication interface for injection molding machine or extruder

Used to connect external temperature control modules, weighing systems, or distributed control nodes

Multi point communication capability supports linkage between complex devices

Communication between frequency converter or servo drive

Realize parameter reading and writing of third-party driving devices through RS-485

Support industrial communication protocols such as MODBUS RTU

Fieldbus communication

Connect sensors, instruments, operation panels, and other devices using RS-485 interfaces

Building a multi master and multi slave control structure

Industrial networking and long-distance communication

Stable remote device serial communication in factory environment (up to 1200 meters)

Improve the scalability of automation systems

2.产      品      展      示
