KEBA K-FTC-AN/B连接板 PDF资料
1.产 品 资 料 介 绍:
中文资料:
一、产品概述
KEBA K-FTC-AN/B 是一款专为 KEBA 控制系统设计的 信号连接板(Connection Board),主要用于模拟信号(Analog)模块与现场设备之间的电气连接和信号分配。它起到信号转换、隔离、布线简化的作用,通常作为模拟输入/输出模块(如 E-ANA 系列)与传感器、执行器之间的中介接口。该模块具备高可靠性和清晰的接线结构,适用于各种工业现场。
二、技术参数
型号:K-FTC-AN/B
功能类型:模拟信号连接板 / 接线端子板
适配模块:适用于 KEBA 模拟量 I/O 模块(如 E-ANA 系列)
通道类型:支持多通道模拟输入和输出信号连接
接线方式:螺丝式或弹簧式接线端子,简化接线作业
信号类型:支持 0–10V、4–20mA 等常用模拟信号制式
安装方式:DIN 导轨安装
防护等级:IP20(电控柜内部使用)
工作电压:依据连接模块供电(通常为 24V DC 系统)
尺寸结构:紧凑型工业标准卡件结构,节省配电箱空间
三、应用领域
工业自动化系统
用于将模拟信号模块与传感器(如温度、压力、流量等)或执行器(如变频器、伺服驱动)进行连接。
注塑控制平台
用于传递模具温控、压力监控等模拟信号至 KEBA 控制器。
机器人集成系统
连接现场模拟控制组件,确保信号稳定输入输出。
OEM 定制自动化设备
作为通用接口板使用,便于模块化设计与维护。
英文资料:
1、 Product Overview
KEBA K-FTC-AN/B is a signal connection board designed specifically for KEBA control systems, mainly used for electrical connection and signal distribution between analog signal modules and field devices. It plays a role in signal conversion, isolation, and simplified wiring, usually serving as an intermediary interface between analog input/output modules (such as the E-ANA series) and sensors and actuators. This module has high reliability and clear wiring structure, suitable for various industrial sites.
2、 Technical parameters
Model: K-FTC-AN/B
Function type: Analog signal connection board/terminal block
Adaptation module: Suitable for KEBA analog I/O modules (such as E-ANA series)
Channel type: Supports multi-channel analog input and output signal connections
Wiring method: screw type or spring type terminal block, simplifying wiring operations
Signal type: Supports commonly used analog signal formats such as 0-10V and 4-20mA
Installation method: DIN rail installation
Protection level: IP20 (for use inside the electrical control cabinet)
Working voltage: powered by the connected module (usually 24V DC system)
Size structure: Compact industrial standard card structure, saving distribution box space
3、 Application Fields
Industrial automation system
Used to connect analog signal modules with sensors (such as temperature, pressure, flow, etc.) or actuators (such as frequency converters, servo drives).
Injection control platform
Used to transmit analog signals such as mold temperature control and pressure monitoring to the KEBA controller.
Robot Integrated System
Connect the on-site simulation control components to ensure stable signal input and output.
OEM customized automation equipment
As a universal interface board, it is convenient for modular design and maintenance.
