KEBA HT4-221示教器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
KEBA HT4-221 示教器是一款工业机器人与自动化设备的便携式操作终端，专用于机器人动作示教、程序编辑及设备参数调节。它配备直观的人机界面，支持实时监控与故障诊断，帮助用户高效完成机器人编程与调试工作。
技术参数：
显示屏：彩色液晶显示屏，具备良好可视性
输入方式：物理按键、旋钮控制，部分型号支持触摸操作
通信接口：
RS232/RS485 串口
USB 接口（根据版本不同可能支持）
电源供应：内置可充电电池，支持外接 24V DC 电源供电
工作环境温度：0°C 至 +50°C
防护等级：通常为 IP54，适合工业现场应用
重量和尺寸：便携设计，便于手持操作与现场使用
应用领域：
1. 工业机器人示教与编程
实时录制机器人运动轨迹与操作步骤，生成程序指令。
2. 设备参数设置与调整
对机器人或自动化设备的运动参数、速度、加速度等进行配置。
3. 运行状态监控与故障诊断
实时显示设备状态，支持错误报警及故障排查。
4. 维护与升级支持
支持固件升级及系统维护操作。
英文资料：
The KEBA HT4-20656 teaching pendant is a human-machine interaction device designed specifically for industrial robots and automation equipment. It is mainly used for teaching programming, parameter setting, and operation monitoring of robot actions. This teaching pendant combines portability and high functionality, supports an intuitive operating interface, and is convenient for on-site debugging and maintenance.
Technical parameters:
Display screen: Color LCD display screen, with a resolution suitable for displaying the robot's operating status and menu interface
Input methods: multifunctional buttons, knobs, and touch buttons (depending on the specific model)
Communication interface:
RS232 or RS485 serial port
May support USB or Ethernet interfaces (specific version confirmed)
Power supply: built-in rechargeable battery or external 24V DC power supply
Working temperature: 0 ° C to+50 ° C
Protection level: generally IP54, suitable for industrial site environment
Weight and size: Portable design, easy to hold and operate
Application areas:
1. Industrial robot demonstration programming
Directly teach the robot trajectory, record actions, and edit programs.
2. Parameter settings for automation equipment
Adjust control parameters, operating modes, and process parameters.
3. On site monitoring and debugging
Real time monitoring of robot or equipment status for easy troubleshooting.
4. Maintenance and Upgrade
Complete firmware upgrades, system maintenance, and other operations through a teaching pendant.
Product advantages:
Easy to operate: user-friendly interface, suitable for quick on-site operation
High compatibility: supports multiple KEBA robots and control systems
Durable and sturdy: Industrial grade design, suitable for harsh on-site environments
Rich in functions: integrating teaching, monitoring, and parameter adjustment into one
2.产 品 展 示
