KEBA D1633C控制电路板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
KEBA D1633C 控制电路板是 KEBA 工业自动化系统中的一款核心嵌入式控制模块，主要用于处理现场信号、协调外设接口以及实现关键逻辑控制功能。它通常集成在 KEBA 的注塑机、自动化单元、伺服控制系统或嵌入式控制平台中，作为内部控制系统的一部分。
该板卡可能属于 KEBA KeControl、KePlast 或 KeMotion 系统中的扩展功能模块，负责数字控制、模拟信号处理或总线通信任务。
技术参数：
注：由于 D1633C 为 KEBA 内部型号，其部分具体参数取决于定制版本或所属产品系列，下列为典型特征：
电路板类型：多功能工业控制板（可定制 I/O 与通信功能）
信号处理能力：支持数字量输入输出、模拟量处理及通讯接口扩展
主控芯片：工业级嵌入式 MCU 或 FPGA（依配置）
通信支持：
可选 RS232、RS485、CAN、Ethernet、SPI 等接口
与主控系统通过背板总线或扁平排线连接
输入/输出通道（依配置）：
数字输入（24V DC）×8～16
数字输出（继电器或晶体管）×8～16
模拟输入（0–10V 或 4–20mA）×2～8
模拟输出（0–10V）×2～4
供电电压：24V DC（±10%）
工作温度：0°C ～ +55°C
电路板结构：4层以上工业级 PCB，带有防干扰保护
安装方式：插拔式、螺丝孔固定或专用机箱卡槽安装
状态指示：板载 LED 指示运行状态与通道状态
应用领域：
1. 注塑控制系统（如 KePlast 平台）
控制板用于处理射出、保压、模具温度调节等过程信号。
2. 包装机械控制单元
实现高速传感器输入与执行器输出控制，协调多轴同步。
3. 工业机器人嵌入式控制系统
用于处理编码器反馈、伺服驱动控制及通信数据分发。
4. 运动控制平台
管理伺服驱动器、信号接口与过程逻辑，实现精密控制。
5. 设备控制与数据采集系统（SCADA 接入）
执行数据采集任务，并通过通信接口上传至主控制系统。
英文资料：
The KEBA D1633C control circuit board is a core embedded control module in KEBA industrial automation systems, mainly used for processing field signals, coordinating peripheral interfaces, and implementing key logic control functions. It is usually integrated into KEBA's injection molding machines, automation units, servo control systems, or embedded control platforms as part of the internal control system.
This board may belong to the extension function module in KEBA KeControl, KePlast, or KeMotion systems, responsible for digital control, analog signal processing, or bus communication tasks.
Technical parameters:
Note: As D1633C is an internal model of KEBA, some of its specific parameters depend on the customized version or the product series it belongs to. The following are typical features:
Circuit board type: Multi functional industrial control board (customizable with I/O and communication functions)
Signal processing capability: supports digital input/output, analog processing, and communication interface expansion
Main control chip: Industrial grade embedded MCU or FPGA (depending on configuration)
Communication support:
Optional RS232, RS485, CAN, Ethernet, SPI and other interfaces
Connected to the main control system through backplane bus or flat cable
Input/output channels (according to configuration):
Digital input (24V DC) × 8-16
Digital output (relay or transistor) x 8-16
Analog input (0-10V or 4-20mA) x 2-8
Analog output (0-10V) × 2-4
Power supply voltage: 24V DC (± 10%)
Working temperature: 0 ° C to+55 ° C
Circuit board structure: Industrial grade PCB with 4 or more layers, equipped with anti-interference protection
Installation method: plug-in, screw hole fixed or dedicated chassis card slot installation
Status indication: Onboard LED indicates operating status and channel status
Application areas:
1. Injection control system (such as KePlast platform)
The control board is used to process signals such as injection, holding pressure, and mold temperature adjustment.
2. Packaging machinery control unit
Realize high-speed sensor input and actuator output control, coordinate multi axis synchronization.
3. Embedded control system for industrial robots
Used for processing encoder feedback, servo drive control, and communication data distribution.
4. Motion control platform
Manage servo drives, signal interfaces, and process logic to achieve precise control.
5. Equipment Control and Data Acquisition System (SCADA Access)
Execute data collection tasks and upload them to the main control system through communication interfaces.
