KEBA T50-ADP示教器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
KEBA T50-ADP 示教器** 是 KEBA 推出的中高端人机交互设备，用于机器人系统、注塑设备、自动化生产线等工业场景中的程序编写、路径示教、参数设置与实时监控。作为 T50 系列的一员，T50-ADP 具备触控屏、功能按键、安全控制元件等标准功能，支持多语言操作界面，适用于多类型自动化设备。
技术参数：
显示屏：7 英寸 TFT 彩色液晶触摸屏
分辨率：800×480（WVGA）
触控方式：电阻式触摸屏，支持戴手套操作
控制按键：
多个可编程功能按键
方向控制、确认、启动/停止等物理按键
安全功能：
红色急停按钮（符合 EN ISO 13850）
三段式使能开关（左手或右手持握）
通信接口：
USB 接口（程序导入导出）
以太网或专用通信端口（连接控制器）
供电方式：通过主系统供电，典型 24V DC
结构设计：
工业级耐冲击外壳
防尘防油设计，适应恶劣环境
重量：约 1.2～1.5 kg（适合手持长期操作）
工作环境温度：0°C 至 +50°C
应用领域：
1. 工业机器人路径示教
用于六轴或多轴工业机器人示教路径点位、轨迹规划、速度调试等。
2. 注塑与橡胶成型机
实时监控锁模、注射、保压等工艺过程参数，进行快捷修改与操作。
3. 自动化生产线调试
控制输送、装配、上下料等子系统设备，便于故障排查和状态检查。
4. 包装与贴标设备人机操作
对热封、贴标、送膜等功能进行人工辅助操作与参数设定。
5. 系统维护与故障诊断
支持设备日志查看、报警管理、设备测试指令发送等运维操作。
英文资料：
The KEBA T50-ADP teaching pendant is a mid to high end human-machine interaction device launched by KEBA, used for programming, path teaching, parameter setting, and real-time monitoring in industrial scenarios such as robot systems, injection molding equipment, and automated production lines. As a member of the T50 series, T50-ADP is equipped with standard functions such as touch screen, function buttons, and safety control components. It supports multiple language operation interfaces and is suitable for various types of automation equipment.
Technical parameters:
Display screen: 7-inch TFT color LCD touch screen
Resolution: 800 × 480 (WVGA)
Touch mode: resistive touch screen, supports glove operation
Control buttons:
Multiple programmable function keys
Physical buttons for direction control, confirmation, start/stop, etc
Security function:
Red emergency stop button (compliant with EN ISO 13850)
Three stage enable switch (held with left or right hand)
Communication interface:
USB interface (program import and export)
Ethernet or dedicated communication port (connected to controller)
Power supply method: Powered by the main system, typically 24V DC
Structural design:
Industrial grade impact resistant shell
Dustproof and oil proof design, suitable for harsh environments
Weight: Approximately 1.2-1.5 kg (suitable for long-term handheld operation)
Working environment temperature: 0 ° C to+50 ° C
Application areas:
1. Industrial robot path teaching
Used for teaching path points, trajectory planning, speed debugging, etc. of six axis or multi axis industrial robots.
2. Injection molding and rubber forming machines
Real time monitoring of process parameters such as mold locking, injection, and pressure maintenance for quick modification and operation.
3. Debugging of automated production line
Control subsystem equipment such as conveying, assembly, loading and unloading to facilitate troubleshooting and status checks.
4. Packaging and labeling equipment human-machine operation
Manually assist in the operation and parameter setting of functions such as heat sealing, labeling, and film feeding.
5. System maintenance and fault diagnosis
Support operation and maintenance operations such as device log viewing, alarm management, and device testing instruction sending.
2.产 品 展 示
