KEBA K2-400 SC440/A通信模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
KEBA K2-400 SC440/A 通信模块** 是 KEBA 自动化系统中用于主控单元与外部设备之间进行工业通信的关键模块，支持多种通信协议与现场总线连接方式。该模块广泛应用于注塑机、包装机、机器人系统以及自动化生产线中，作为数据交互与指令传输的桥梁。
技术参数：
模块类型：工业通信扩展模块
接口类型：支持 RS-232/RS-485、CAN、Ethernet（依具体配置）
通信协议：支持 Modbus RTU、CANopen、EtherNet/IP、PROFIBUS DP 等
数据传输速率：最高可达 12 Mbps（取决于接口类型）
电源供电：由控制系统母板供电（通常为 5V 或 24V DC）
安装方式：插入式或背板安装，适配 KEBA KeControl 系列
模块尺寸：标准工业尺寸，便于集成至控制柜
工作环境温度：0°C 至 +50°C
电气隔离：各通信端口具备电气隔离，增强抗干扰能力
状态指示：LED 指示灯显示通信状态和故障信息
应用领域：
1. 注塑与成型设备通信系统
用于主控制器与温控模块、驱动器、阀岛、I/O 扩展模块间的数据交换。
实现控制闭环内各部件的高效协调。
2. 包装与输送自动化系统
连接传感器、执行器、视觉系统等外部设备，实现快速通信响应。
用于同步多个设备状态、位置与指令。
3. 机器人集成系统
支持与多品牌 PLC、驱动器及上位机系统（SCADA）通信。
提供高速且稳定的现场总线连接。
4. MES/ERP 系统数据接入
实现现场控制系统与工厂信息管理系统之间的数据桥接。
支持通过以太网或串口方式上传设备运行数据。
5. 工业网关与远程监控
作为网关模块，桥接多种通信标准，便于系统远程访问和运维。
英文资料：
The KEBA K2-400 SC440/A communication module * * is a key module used in the KEBA automation system for industrial communication between the main control unit and external devices, supporting multiple communication protocols and fieldbus connection methods. This module is widely used in injection molding machines, packaging machines, robot systems, and automated production lines as a bridge for data exchange and instruction transmission.
Technical parameters:
Module type: Industrial Communication Expansion Module
Interface type: Supports RS-232/RS-485, CAN, Ethernet (depending on specific configuration)
Communication protocol: Supports Modbus RTU, CANopen, EtherNet/IP, PROFIBUS DP, etc
Data transmission rate: up to 12 Mbps (depending on interface type)
Power supply: Powered by the control system motherboard (usually 5V or 24V DC)
Installation method: plug-in or backplate installation, compatible with KEBA KeControl series
Module size: Standard industrial size, easy to integrate into control cabinets
Working environment temperature: 0 ° C to+50 ° C
Electrical isolation: Each communication port has electrical isolation to enhance anti-interference capability
Status indication: LED indicator light displays communication status and fault information
Application areas:
1. Injection molding and molding equipment communication system
Used for data exchange between the main controller and temperature control modules, drivers, valve islands, and I/O expansion modules.
Realize efficient coordination of various components within the control loop.
2. Packaging and Conveyor Automation System
Connect external devices such as sensors, actuators, and vision systems to achieve fast communication response.
Used to synchronize the status, location, and instructions of multiple devices.
3. Robot integrated system
Support communication with multiple brands of PLCs, drivers, and SCADA systems.
Provide high-speed and stable fieldbus connections.
4. MES/ERP system data access
Realize data bridging between on-site control system and factory information management system.
Support uploading device operation data through Ethernet or serial port.
5. Industrial gateway and remote monitoring
As a gateway module, it bridges multiple communication standards, facilitating remote access and operation of the system.
2.产 品 展 示
