KEBA AR281分析输入板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
产品概述：
KEBA AR281 分析输入板** 是 KEBA 自动化系统中的模拟输入扩展模块，主要用于采集来自外部模拟传感器的信号，例如温度、压力、电流、电压等模拟量信号。该模块一般与 KEBA KeControl 系列控制器（如 CU211、CU313 等）配套使用，适用于多种高精度模拟数据采集场合。
技术特性简要：
模块功能：模拟信号输入采集
信号类型：支持电压输入、热电偶、电流输入等（根据配置不同）
输入通道数：典型为 4 至 8 路高精度模拟输入通道
分辨率：12 位或 16 位 A/D 转换
绝缘性：输入通道间电气隔离，抗干扰能力强
接口方式：通过系统总线连接至主控单元
使用环境：适应工业温度范围，支持导轨或模块化安装
产品应用领域：
1. 注塑机与橡塑设备
用于采集模具温度、熔胶压力、液压系统压力等模拟量参数。
配合控制器实现闭环温控与压力补偿控制。
适用于需要精密温度管理的多区加热系统。
2. 工业过程控制系统
采集液位计、流量计、温度变送器等设备的模拟信号。
应用于化工、制药、食品加工等连续性生产线的实时参数监控。
提供精确数据支撑现场自动调节控制。
3. 自动化测试平台
实时采集测试点的电压、电流、传感器响应值等。
用于功能测试、可靠性测试、产品校准与数据记录。
特别适合多信号点同步采集的检测设备。
4. 机床及数控设备
采集冷却液温度、主轴负载信号、振动传感器模拟输出等。
支持基于状态的维护判断与智能告警系统。
配合振动分析与能效优化功能。
英文资料：
Product Overview:
The KEBA AR281 Analysis Input Board is an analog input expansion module in the KEBA automation system, mainly used to collect signals from external analog sensors, such as temperature, pressure, current, voltage and other analog signals. This module is generally used in conjunction with KEBA KeControl series controllers (such as CU211, CU313, etc.) and is suitable for various high-precision analog data acquisition scenarios.
Brief technical characteristics:
Module function: Analog signal input acquisition
Signal type: Supports voltage input, thermocouple, current input, etc. (depending on configuration)
Number of input channels: typically 4 to 8 high-precision analog input channels
Resolution: 12 bit or 16 bit A/D conversion
Insulation: Electrical isolation between input channels, strong anti-interference ability
Interface method: Connected to the main control unit through the system bus
Usage environment: Suitable for industrial temperature range, supports rail or modular installation
Product application areas:
1. Injection molding machines and rubber equipment
Used to collect analog parameters such as mold temperature, melt adhesive pressure, hydraulic system pressure, etc.
Cooperate with the controller to achieve closed-loop temperature control and pressure compensation control.
Suitable for multi zone heating systems that require precise temperature management.
2. Industrial process control system
Collect analog signals from devices such as level gauges, flow meters, and temperature transmitters.
Real time parameter monitoring applied to continuous production lines in chemical, pharmaceutical, food processing, and other industries.
Provide precise data to support on-site automatic adjustment and control.
3. Automated testing platform
Real time collection of voltage, current, sensor response values, etc. at testing points.
Used for functional testing, reliability testing, product calibration, and data recording.
Especially suitable for detection equipment that synchronously collects multiple signal points.
4. Machine tools and CNC equipment
Collect coolant temperature, spindle load signal, vibration sensor analog output, etc.
Support state based maintenance judgment and intelligent alarm system.
Cooperate with vibration analysis and energy efficiency optimization functions.
2.产 品 展 示
