KEBA T70-rqa-AK0-LK 触摸屏 PDF资料
1.产 品 资 料 介 绍：
中文资料：
KEBA T70-rqa-AK0-LK 是 KEBA 推出的 KeTop T70 系列便携式触摸屏终端，通常用于机器人示教、现场调试及工业设备操作。该型号具有丰富的输入控制功能，集成人机界面、控制按键和安全操作部件，适用于工业自动化中需要移动控制和高安全性的场合。
技术参数：
显示屏：7 英寸 WSVGA 分辨率（1024×600 像素）TFT 彩色液晶屏
触摸方式：模拟电阻式触摸屏，支持手指或触控笔操作
前面板按键：最多可配置 21 个薄膜按键
后部按键：可选配 12 个功能按键
操作开关：支持 2、4、16 段选择开关及 2 或 3 位钥匙开关
紧急停止：标配急停按钮，满足工业安全标准
使能开关：三段式安全使能开关
LED 指示灯：内置 4 个状态指示灯
供电电压：24 VDC
工作温度：0 至 +50 摄氏度
存储温度：-20 至 +60 摄氏度
外壳设计：人体工学手持结构，防护等级适用于工业环境
应用场景：
机器人示教与调试
作为工业机器人或协作机器人系统的手持示教器，用于轨迹设定、参数调节和状态监控。
数控与自动化设备控制
应用于数控加工中心、自动装配线、输送设备等现场作业控制，提升调试灵活性。
工业设备远程操作
在复杂或危险环境中提供移动式远程人机界面，避免操作人员靠近高风险区域。
注塑机和成型设备
配合 KEBA KePlast 系统，为注塑机操作人员提供直观控制界面和设备状态反馈。
自动化产线人机交互
在自动化生产线、包装线等需快速人机交互的场合使用，提高操作效率与安全等级。
英文资料：
KEBA T70-rqa-AK0-LK is the KeTop T70 series portable touch screen terminal launched by KEBA, commonly used for robot teaching, on-site debugging, and industrial equipment operation. This model has rich input control functions, integrated human-machine interface, control buttons, and safety operation components, suitable for situations in industrial automation that require mobile control and high safety.
Technical parameters:
Display screen: 7-inch WSVGA resolution (1024 × 600 pixels) TFT color LCD screen
Touch mode: Analog resistive touch screen, supporting finger or stylus operation
Front panel buttons: up to 21 film buttons can be configured
Rear buttons: optional 12 function buttons
Operation switch: supports 2, 4, 16 segment selection switches and 2 or 3 position key switches
Emergency stop: Standard emergency stop button to meet industrial safety standards
Enable switch: three-stage safety enable switch
LED indicator light: Built in 4 status indicator lights
Supply voltage: 24 VDC
Working temperature: 0 to+50 degrees Celsius
Storage temperature: -20 to+60 degrees Celsius
Shell design: Ergonomic handheld structure, protection level suitable for industrial environments
Application scenarios:
Robot Teaching and Debugging
As a handheld teaching pendant for industrial robots or collaborative robot systems, it is used for trajectory setting, parameter adjustment, and status monitoring.
Numerical Control and Automation Equipment Control
Applied to on-site operation control of CNC machining centers, automatic assembly lines, conveying equipment, etc., to enhance debugging flexibility.
Remote operation of industrial equipment
Provide a mobile remote human-machine interface in complex or hazardous environments to prevent operators from approaching high-risk areas.
Injection molding machines and molding equipment
Cooperate with KEBA KePlast system to provide intuitive control interface and equipment status feedback for injection molding machine operators.
Automated production line human-machine interaction
Used in automated production lines, packaging lines, and other situations that require fast human-machine interaction to improve operational efficiency and safety levels.
2.产 品 展 示
