UNIOP eTOP506U2P1触摸面板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
UniOP eTOP506U2P1 触摸面板简介
一、产品概述
UniOP eTOP506U2P1 是一款工业级人机界面（HMI）触摸面板，配备 5.7 英寸 TFT 彩色显示屏，支持电阻式触摸，适合多种自动化控制系统。
二、主要技术参数
显示屏尺寸：5.7 英寸 TFT 彩色液晶
分辨率：320×240 像素（QVGA）
触摸方式：电阻式触摸屏
背光类型：LED 背光，亮度可调
通信接口：双以太网口、两个 USB 主机端口、SD 卡插槽
扩展功能：支持可插拔模块，连接现场总线和 I/O 模块
电源输入：24V DC（±10%）
安装方式：面板嵌入式安装，安装深度小于 50 毫米
软件支持：兼容 JMobile 软件平台，支持图形界面设计、宏命令、报警管理、历史数据、配方管理、多语言等功能
三、典型应用领域
工业自动化设备控制，如机械设备操作界面
楼宇自动化与能源管理，如空调、电梯控制
过程监控与数据管理，包括报警记录、趋势分析
系统集成与网络通信，支持 PLC、SCADA、OPC Server 集成
维修与替代用途，作为旧型号替代或备件
英文资料：
Introduction to UniOP eTOP506U2P1 Touch Panel
1、 Product Overview
UniOP eTOP506U2P1 is an industrial grade human-machine interface (HMI) touch panel equipped with a 5.7-inch TFT color display screen, supporting resistive touch and suitable for various automation control systems.
2、 Main technical parameters
Display screen size: 5.7-inch TFT color LCD
Resolution: 320 × 240 pixels (QVGA)
Touch mode: resistive touch screen
Backlight type: LED backlight, adjustable brightness
Communication interface: dual Ethernet ports, two USB host ports, SD card slot
Extension function: Supports pluggable modules, connects fieldbus and I/O modules
Power input: 24V DC (± 10%)
Installation method: panel embedded installation, installation depth less than 50 millimeters
Software support: compatible with JMobile software platform, supporting graphical interface design, macro commands, alarm management, historical data, recipe management, multiple languages and other functions
3、 Typical application areas
Industrial automation equipment control, such as mechanical equipment operation interface
Building automation and energy management, such as air conditioning and elevator control
Process monitoring and data management, including alarm recording, trend analysis
System integration and network communication, supporting PLC, SCADA, OPC Server integration
Repair and replacement purposes, as a replacement or spare part for old models
2.产 品 展 示
