UNIOP eTOP133C-0050触摸屏 PDF资料
1.产 品 资 料 介 绍：
中文资料：
一、产品概述
eTOP133C‑0050 属于 UniOP eTOP 系列，是一款带 10.4 英寸 TFT 彩色触摸屏的工业 HMI 面板，采用电阻式触控技术，提供丰富通信接口与功能扩展，适合工业自动化控制系统。
二、主要技术参数（参考同系列规格）
显示屏：10.4″ TFT 彩色 LCD
分辨率：640 × 480 像素（VGA）
触控方式：电阻式触摸屏
用户存储：约 64 MB 内存，用于程序与数据存储
通信接口：内置以太网（10/100 Mbps）、USB 端口，支持 RS‑232（打印机/PC）、RS‑485（PLC），可插入模块扩展现场总线如 Profibus DP、CANopen、DeviceNet、Interbus 等
电源输入：24 V DC（±10 %）
环境温度：常规工作温度范围约 0–45 °C
软件支持：支持 UniOP Designer 或 JMobile 软件平台，拥有宏脚本、报警管理、历史数据记录、配方管理、多语言界面与报表功能
用户界面功能：支持 SVG 矢量图形、TrueType 字体、向量图形绘制、UniNet 网络通信协议
三、典型应用领域
中大型工业自动化控制
作为控制终端，在装配线、泵站、包装设备、CNC 机床等系统中执行监控与参数设置。过程监控与数据管理
提供报警记录、趋势绘图、配方切换、多级密码保护和报表打印功能，便于设备监调与维护追溯。楼宇自动化与能源管理
用于 HVAC、水处理、电力系统等场景的本地操作界面，实时显示系统状态并接入现场总线控制。系统集成与网络通信接口扩展
通过 USB、以太网和现场总线模块，可与 PLC、SCADA、OPC Server、UniNet 网络系统集成，在分布式控制架构中沟通数据。维修与替代使用
由于该型号已停产，市场上常见库存件或翻新件，适合作为早期 eTOP33C 面板的替代或维修备件。
英文资料：
1、 Product Overview
ETOP133C-0050 belongs to the UniOP eTOP series and is an industrial HMI panel with a 10.4-inch TFT color touch screen. It uses resistive touch technology and provides rich communication interfaces and functional extensions, making it suitable for industrial automation control systems.
2、 Main technical parameters (refer to specifications of the same series)
Display screen: 10.4 "TFT color LCD
Resolution: 640 × 480 pixels (VGA)
Touch mode: resistive touch screen
User storage: Approximately 64 MB of memory for program and data storage
Communication interface: Built in Ethernet (10/100 Mbps), USB port, supports RS-232 (printer/PC), RS-485 (PLC), can insert modules to expand fieldbus such as Profibus DP, CANopen, DeviceNet, Interbus, etc
Power input: 24V DC (± 10%)
Environmental temperature: The normal operating temperature range is about 0-45 ° C
Software support: Supports UniOP Designer or JMobile software platforms, with macro scripting, alarm management, historical data recording, recipe management, multilingual interface, and reporting functions
User interface features: Supports SVG vector graphics, TrueType fonts, vector graphics drawing, UniNet network communication protocol
3、 Typical application areas
Large scale industrial automation control
As a control terminal, it performs monitoring and parameter setting in systems such as assembly lines, pump stations, packaging equipment, CNC machine tools, etc.
Process monitoring and data management
Provide alarm recording, trend plotting, recipe switching, multi-level password protection, and report printing functions for equipment monitoring, debugging, maintenance, and traceability.
Building Automation and Energy Management
A local operating interface for HVAC, water treatment, power systems, and other scenarios, displaying system status in real-time and connected to fieldbus control.
System integration and network communication interface expansion
Through USB, Ethernet, and fieldbus modules, it can be integrated with PLC, SCADA, OPC Server, UniNet network systems to communicate data in a distributed control architecture.
Repair and Alternative Use
Due to the discontinuation of this model, it is a common stock or refurbished part in the market, suitable as a replacement or repair spare part for early eTOP33C panels.
