UNIOP ETOP11-0050 显示器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
UniOP eTOP11-0050 显示器简介及应用领域
一、产品概述
UniOP eTOP11-0050 是 Exor 公司推出的一款工业级触摸屏人机界面（HMI），配有 5.6 英寸 STN 彩色液晶显示屏，支持电阻式触摸操作。该设备结构紧凑、功能可靠，适用于多种工业环境。
主要技术参数：
显示屏尺寸：5.6 英寸
分辨率：320×240 像素（1/4 VGA）
触摸屏类型：电阻式触摸屏
电源输入：24V DC
安装方式：面板嵌入式安装
通信接口：可选串口、以太网、CAN、Profibus 等扩展模块
编程软件：支持 UniOP Designer 或 JMobile Studio
存储容量：标准支持约32MB用户程序空间
状态：该型号为早期型号，目前已停产，市场上以库存或替代型号为主
二、典型应用领域
工业设备控制界面
应用于各类机械设备如注塑机、切割机、包装机、数控机床等，作为人机交互平台，显示运行状态、报警信息并进行参数设置。生产线自动化系统
在装配线、流水线、检测系统中用于数据监控和操作控制，提升自动化效率。能源与环保设备监控
应用于供水、锅炉、风机、泵站等系统中，实现数据可视化和报警功能。楼宇自动化系统
用于中央空调、照明控制、电梯管理等子系统，提供直观的图形界面供用户操作。电力与配电监控
应用于配电柜、变电站、UPS 系统中，便于远程监控和数据采集。过程控制行业
涉及食品、制药、化工等行业的温度、流量、配方等参数控制与记录。教育与实验平台
因体积小巧、功能实用，适合用于教学和控制系统模拟实验环境。
英文资料：
Introduction and Application Fields of UniOP eTOP11-0050 Monitor
1、 Product Overview
UniOP eTOP11-0050 is an industrial grade touch screen human-machine interface (HMI) launched by Exor, equipped with a 5.6-inch STN color LCD display screen and supporting resistive touch operation. The device has a compact structure, reliable functions, and is suitable for various industrial environments.
Main technical parameters:
Display screen size: 5.6 inches
Resolution: 320 × 240 pixels (1/4 VGA)
Touch screen type: resistive touch screen
Power input: 24V DC
Installation method: panel embedded installation
Communication interface: optional expansion modules such as serial port, Ethernet, CAN, Profibus, etc
Programming software: supports UniOP Designer or JMobile Studio
Storage capacity: Standard supports approximately 32MB of user program space
Status: This model is an early model that has been discontinued and is mainly available in stock or as a substitute model in the market
2、 Typical application areas
Industrial equipment control interface
Applied to various mechanical equipment such as injection molding machines, cutting machines, packaging machines, CNC machine tools, etc., as a human-machine interaction platform, it displays operating status, alarm information, and performs parameter settings.
Production line automation system
Used for data monitoring and operation control in assembly lines, assembly lines, and inspection systems to improve automation efficiency.
Monitoring of Energy and Environmental Protection Equipment
Applied in water supply, boiler, fan, pump station and other systems to achieve data visualization and alarm functions.
Building Automation System
Used for subsystems such as central air conditioning, lighting control, elevator management, etc., providing intuitive graphical interfaces for users to operate.
Electricity and distribution monitoring
Applied in distribution cabinets, substations, and UPS systems, it facilitates remote monitoring and data collection.
Process control industry
Control and record parameters such as temperature, flow rate, and formula related to industries such as food, pharmaceuticals, and chemicals.
Education and Experimental Platform
Due to its compact size and practical functions, it is suitable for use in teaching and control system simulation experimental environments.
2.产 品 展 示
