UNIOP eTOP10C-0050面板玻璃 PDF资料
1.产 品 资 料 介 绍：
中文资料：
一、产品名称
UniOP eTOP10C-0050 面板玻璃（触控玻璃）
二、所属设备简介
eTOP10C-0050 是 EXOR UniOP 系列的一款紧凑型工业触摸屏操作面板，具备彩色图形显示和电阻式触控功能，广泛应用于工业自动化设备中。
三、面板玻璃功能与规格说明
| 项目 | 参数说明 |
|---|---|
| 面板类型 | 前置电阻式触摸屏玻璃（含透明保护层） |
| 显示区域 | 约 5.7 英寸视窗，对应设备主显示屏 |
| 显示屏配合 | 彩色 TFT LCD（320 × 240 QVGA 分辨率） |
| 触控类型 | 电阻式单点触控（带导电薄膜，与 LCD 屏贴合） |
| 材质结构 | 透明玻璃 / 亚克力前板 + ITO 导电薄膜 |
| 安装方式 | 嵌入设备前面板，通过螺丝夹或卡扣固定 |
| 防护等级 | 正面支持 IP65（装配后，配合密封圈使用） |
| 使用环境 | 防油、防尘、防轻度刮擦，适应工业操作环境 |
| 可替换性 | 可单独更换（需断电拆机），兼容原厂型号组件 |
四、应用说明
面板玻璃是人机交互的直接界面，损坏后会影响触摸响应和显示可视性
支持通过 EXOR 或第三方渠道采购原装或兼容型号面板玻璃组件
更换需专业人员操作，以防划伤主机或损坏触摸接口排线
英文资料：
1、 Product Name
UniOP eTOP10C-0050 Panel Glass (Touch Glass)
2、 Equipment Introduction
ETOP10C-0050 is a compact industrial touch screen operation panel from the EXOR UniOP series, featuring color graphic display and resistive touch functionality, widely used in industrial automation equipment.
3、 Function and specification description of panel glass
Project parameter description
Panel type: Front facing resistive touch screen glass (including transparent protective layer)
Display area of approximately 5.7-inch window, corresponding to the main display screen of the device
Display screen paired with color TFT LCD (320 × 240 QVGA resolution)
Touch type: resistive single point touch (with conductive film, attached to LCD screen)
Material structure: transparent glass/acrylic front panel+ITO conductive film
Installation method: Embed the device front panel and fix it with screw clips or buckles
The protection level supports IP65 on the front (used in conjunction with sealing rings after assembly)
The usage environment is oil resistant, dust-proof, and resistant to light scratches, suitable for industrial operating environments
Replaceability: can be replaced separately (requires power-off disassembly), compatible with original model components
4、 Application Description
Panel glass is a direct interface for human-computer interaction, and damage can affect touch response and display visibility
Support purchasing original or compatible model panel glass components through EXOR or third-party channels
Replacement requires professional personnel to operate to prevent scratching the host or damaging the touch interface wiring
