When enabled by software, the ABORT switch (S2) generates an interrupt at a
user-programmable level. It is normally used to abort program execution and
return to the debugger. Refer to the VMEchip2 chapter of the MVME197LE,
MVME197DP, and MVME197SP Single Board Computers Programmer’s Reference
Guide for more information.
The six LEDs on the MVME197LE front panel are: FAIL, SCON, RUN, LAN,
VME, and SCSI.
1. The yellow FAIL LED (DS1) is lit when the BRDFAIL signal line is active.
2. The green SCON LED (DS2) is lit when the VMEchip2 is the VMEbus
system controller.
3. The green RUN LED (DS3) is lit when the MC88110 bus MC* pin is low.
4. The green LAN LED (DS4) lights when the LAN chip is the local
peripheral bus master.
5. The green VME LED (DS5) lights when the board is using the VMEbus or
when the board is accessed by the VMEbus.
6. The green SCSI LED (DS6) lights when the SCSI chip is the local peripheral
bus master.Data Bus Structure
The data bus structure is arranged to accommodate the various 8-bit, 16-bit,
32-bit, and 64-bit devices that reside on the module. Refer to the MVME197LE,
MVME197DP, and MVME197SP Single Board Computers Programmer’s Reference
Guide and to the user’s guide for each device to determine its port size, data
bus connection, and any restrictions that apply when accessing the device.
MC88110 MPU
The MVME197LE is based on the MC88000 family and uses one MC88110
microprocessor unit. Refer to the MC88110 Second Generation RISC
Microprocessor User’s Manual for more information.
BOOT ROM
A socket for a 32-pin PLCC/CLCC ROM/EPROM referred to as BOOT ROM
or DROM (Download ROM) is provided. It is organized as a 128K x 8 device,
but as viewed from the processor it looks like a 16K x 64 memory. This
memory is mapped starting at location $FFF80000, but after a local reset it is
also mapped at location 0, providing a reset vector and bootstrap code for the
processor. The DR0 bit in the General Control Register (GCR) of the PCCchip2
must be cleared to disable the BOOT ROM memory map at 0
