Tokyo Electron 2985-445336-W1接口块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Tokyo Electron (TEL) 2985-445336-W1 接口块 — 产品应用领域详解
一、产品功能定位
2985-445336-W1 接口块是 Tokyo Electron 半导体制造设备中的一种信号中继与连接组件，主要用于控制系统与执行元件、传感器、模块间的电气连接和信号分配。它通常集成在设备的机架或控制柜中，用于汇聚、分配或转换控制信号，以保障设备系统的协调运行与维护便利性。
二、主要应用领域
1. 设备信号布线与接口管理平台
作用说明：
接口块将主控板（如控制器模块、I/O 模块）与现场设备（如电磁阀、加热单元、真空开关、传感器）之间的线缆集中连接，起到中继与汇流的作用。典型应用场景：
控制信号的集中接入和统一布线；
接口标准化，便于设备调试与快速更换；
与 I/O 控制模块形成一体化信号管理系统。
2. 信号类型转换或隔离接口
应用功能：
可能包含光耦、电气隔离、滤波元件等功能，保护主控系统免受信号干扰或浪涌影响；
实现不同信号制式（如 TTL → 24V、模拟 → 数字）的转换。
3. 维护与扩展的辅助模块
设计优势：
接线端子清晰，便于现场工程师进行快速布线、诊断与更换；
支持模块级扩展，为未来工艺升级提供灵活接口；
可配合 TEL 控制模块进行单元化管理和模块化升级。
英文资料：
Tokyo Electron (TEL) 2985-445336-W1 Interface Block - Detailed Explanation of Product Application Fields
1、 Product functional positioning
The 2985-445336-W1 interface block is a signal relay and connection component in Tokyo Electron semiconductor manufacturing equipment, mainly used for electrical connections and signal distribution between control systems, actuators, sensors, and modules. It is usually integrated into the rack or control cabinet of the equipment, used to aggregate, distribute, or convert control signals to ensure the coordinated operation and maintenance convenience of the equipment system.
2、 Main application areas
1. Equipment signal wiring and interface management platform
Function description:
The interface block centrally connects the cables between the main control board (such as controller modules, I/O modules) and field devices (such as solenoid valves, heating units, vacuum switches, sensors), serving as a relay and combiner.
Typical application scenarios:
Centralized access and unified wiring of control signals;
Standardization of interfaces facilitates equipment debugging and quick replacement;
Form an integrated signal management system with the I/O control module.
2. Signal type conversion or isolation interface
Application Function:
May include functions such as optocouplers, electrical isolation, filtering components, etc., to protect the main control system from signal interference or surge effects;
Realize the conversion of different signal formats (such as TTL → 24V, analog → digital).
3. Auxiliary modules for maintenance and expansion
Design advantages:
Clear wiring terminals facilitate quick wiring, diagnosis, and replacement by on-site engineers;
Support module level expansion, providing flexible interfaces for future process upgrades;
Can be integrated with TEL control module for modular management and upgrading.
