Tokyo Electron 3S80-000007-11涡轮增压泵 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Tokyo Electron (TEL) 3S80-000007-11 涡轮增压泵 — 产品应用领域详解
一、产品功能定位
3S80-000007-11 涡轮增压泵（Turbo Molecular Pump，简称 TMP）是 Tokyo Electron 半导体设备中用于维持真空环境的核心部件之一。它通常用于中高真空段，具有高速旋转叶轮结构，适用于对洁净度、稳定性要求极高的真空工艺。
二、主要应用领域
1. 半导体真空处理设备的真空系统
核心作用：为晶圆加工腔体（如刻蚀腔、CVD 腔、PVD 腔等）提供中高真空环境；
目标真空范围：10⁻³ Pa 至 10⁻⁶ Pa；
典型设备：
等离子刻蚀设备（Etcher）
原子层沉积（ALD）系统
化学气相沉积（CVD）
金属有机化学气相沉积（MOCVD）
2. 高洁净工艺环境维持
无油结构：涡轮分子泵不使用润滑油，杜绝油污染，适用于超高洁净环境；
低振动/低噪音：适合敏感工艺操作，如薄膜沉积、离子注入、真空退火等；
反应控制：为高精度温控、气流控制提供稳定真空基础。
英文资料：
Tokyo Electron (TEL) 3S80-00007-11 Turbocharging Pump - Product Application Field Detailed Explanation
1、 Product functional positioning
The 3S80-00007-11 Turbo Molecular Pump (TMP) is one of the core components used to maintain a vacuum environment in Tokyo Electron semiconductor equipment. It is usually used in medium to high vacuum sections, with a high-speed rotating impeller structure, suitable for vacuum processes that require extremely high cleanliness and stability.
2、 Main application areas
1. Vacuum system of semiconductor vacuum processing equipment
Core function: To provide a medium to high vacuum environment for wafer processing chambers (such as etching chambers, CVD chambers, PVD chambers, etc.);
Target vacuum range: 10 ⁻³ Pa to 10 ⁻⁶ Pa;
Typical equipment:
Plasma etching equipment (Etcher)
Atomic Layer Deposition (ALD) System
Chemical Vapor Deposition (CVD)
Metal Organic Chemical Vapor Deposition (MOCVD)
2. Maintenance of High Cleanliness Process Environment
Oil free structure: The turbo molecular pump does not use lubricating oil, eliminating oil pollution and suitable for ultra clean environments;
Low vibration/low noise: suitable for sensitive process operations such as thin film deposition, ion implantation, vacuum annealing, etc;
Reaction control: provides a stable vacuum foundation for high-precision temperature control and airflow control.
2.产 品 展 示
