Tokyo Electron 3S86-000280-14继电器模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
TEL Tokyo Electron 3S86-000280-14 继电器模块简介
一、基本信息
产品型号：3S86-000280-14
名称：继电器模块（Relay Board）
制造商：Tokyo Electron Ltd.（TEL）
典型结构代号：CB6S8S-4-M1
应用类型：设备执行电路控制
二、功能与特性
电路切换控制
通过继电器控制外部设备电源回路的通断，如泵、阀门、风扇或加热器等。电气隔离
利用继电器提供控制系统与高压设备之间的隔离，提高整体系统的安全性和稳定性。模块化集成
以插板形式与控制主板或背板连接，便于系统扩展和后期维护更换。
三、应用领域
半导体设备：广泛用于 TEL 的蚀刻机（Etcher）、CVD设备、清洗设备等机型中。
工业自动化控制系统：在需要多点输出控制的场合承担多路输出执行功能。
信号控制与负载驱动：连接至末端负载装置，如继电器柜、电磁阀、电动设备。
英文资料：
Introduction to TEL Tokyo Electron 3S86-000280-14 Relay Module
1、 Basic Information
Product model: 3S86-000280-14
Name: Relay Board
Manufacturer: Tokyo Electron Ltd. (TEL)
Typical structural code: CB6S8S-4-M1
Application type: Device execution circuit control
2、 Function and Features
Circuit switching control
Control the on/off of external device power circuits such as pumps, valves, fans, or heaters through relays.
Electrical isolation
Using relays to provide isolation between the control system and high-voltage equipment, improving the overall safety and stability of the system.
Modular integration
Connect to the control motherboard or backplane in the form of a plug-in board for easy system expansion and later maintenance and replacement.
3、 Application Fields
Semiconductor equipment: widely used in TEL etching machines, CVD equipment, cleaning equipment and other models.
Industrial automation control system: undertakes the function of executing multiple outputs in situations where multi-point output control is required.
Signal control and load drive: connected to end load devices such as relay cabinets, solenoid valves, and electric equipment.
