Tokyo Electron 1880-027845-11采集卡 PDF资料
1.产 品 资 料 介 绍：
中文资料：
TEL Tokyo Electron 1880-027845-11 采集卡（Data Acquisition Card / DAQ） 是一款用于半导体制造设备中的工业级信号采集模块，主要功能是将来自传感器、开关、执行器等子系统的模拟量或数字量信号采集并传输至中央控制系统，实现设备状态监控、工艺反馈和安全联锁等关键控制功能。
以下是该采集卡的详细应用领域与功能说明（无图案）：
一、基本信息
产品型号： 1880-027845-11
产品名称： 采集卡（DAQ Module）
制造商： Tokyo Electron Ltd.（TEL）
所属类别： 工业信号采集模块 / I/O 控制板
二、核心功能
多通道信号采集
支持采集多路模拟信号（Analog Input）与数字信号（Digital Input）；
典型采集信号包括温度、电压、电流、压力、光电状态等。
信号转换与处理
集成高精度 A/D 转换电路（如12-bit或16-bit ADC）；
对模拟信号进行滤波、放大、转换，确保控制系统可直接读取。
实时数据上传
将采集的数据传输至中央控制模块（如 E244 或 BX 系列）；
实现对设备运行状态的实时反馈与处理。
电气隔离与防护设计
通道间具备电气隔离设计，增强设备抗干扰能力；
提供过流、过压保护，提高系统稳定性与可靠性。
英文资料：
TEL Tokyo Electron 1880-027845-11 Data Acquisition Card (DAQ) is an industrial grade signal acquisition module used in semiconductor manufacturing equipment. Its main function is to collect and transmit analog or digital signals from subsystems such as sensors, switches, and actuators to the central control system, achieving key control functions such as equipment status monitoring, process feedback, and safety interlocking.
The following is a detailed application area and functional description of the acquisition card (without graphics):
1、 Basic Information
Product model: 1880-027845-11
Product Name: DAQ Module
Manufacturer: Tokyo Electron Ltd. (TEL)
Category: Industrial signal acquisition module/I/O control board
2、 Core functions
Multi channel signal acquisition
Support the collection of multiple analog signals (Analog Input) and digital signals (Digital Input);
Typical collected signals include temperature, voltage, current, pressure, photoelectric status, etc.
Signal Conversion and Processing
Integrated high-precision A/D conversion circuit (such as 12 bit or 16 bit ADC);
Filter, amplify, and convert analog signals to ensure that the control system can directly read them.
Real time data upload
Transfer the collected data to the central control module (such as E244 or BX series);
Realize real-time feedback and processing of device operating status.
Electrical isolation and protection design
The channels are designed with electrical isolation to enhance the anti-interference ability of the equipment;
Provide overcurrent and overvoltage protection to improve system stability and reliability.
