Tokyo Electron MPC-T0048A-11输入输出模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
TEL Tokyo Electron MPC-T0048A-11 输入输出模块 是一款用于 Tokyo Electron 半导体制造设备中的 I/O（Input/Output）控制组件，广泛用于各种自动化工艺流程的信号采集与设备联动控制。以下是不含图案的详细说明：
一、基本信息
产品型号： MPC-T0048A-11
产品名称： 输入输出模块（I/O Module）
制造商： Tokyo Electron Ltd.（TEL）
功能类别： 数字量/模拟量输入输出接口板
二、主要功能
信号采集与控制
采集外部设备（传感器、限位开关、光电器件等）的输入信号；
输出控制指令信号至执行器（电磁阀、继电器、伺服驱动等）。
设备联动协调
作为工艺设备中多个子系统（如气体、真空、运动平台、温控系统等）之间的接口桥梁；
控制各环节的启停、顺序逻辑、状态反馈，确保流程同步执行。
现场总线或背板通信接口
通过 TEL 专用总线协议或工业标准通信方式（如CAN、RS-485、TTL等）与主控制器（如E244系列）通信；
接口信号标准支持多种电平：24V/TTL/OC 等。
安全与状态监控
配合系统进行故障检测、紧急停机联动、安全互锁等控制逻辑；
可配置为冗余回路或自动复位控制回路，提高设备安全性与可靠性。
英文资料：
The TEL Tokyo Electron MPC-T0048A-11 input/output module is an I/O (Input/Output) control component used in Tokyo Electron semiconductor manufacturing equipment, widely used for signal acquisition and equipment linkage control in various automated process flows. The following is a detailed explanation without patterns:
1、 Basic Information
Product model: MPC-T0048A-11
Product Name: I/O Module
Manufacturer: Tokyo Electron Ltd. (TEL)
Function category: Digital/Analog Input/Output Interface Board
2、 Main functions
Signal acquisition and control
Collect input signals from external devices such as sensors, limit switches, optoelectronic devices, etc;
Output control command signals to actuators (solenoid valves, relays, servo drives, etc.).
Equipment linkage coordination
As an interface bridge between multiple subsystems in process equipment, such as gas, vacuum, motion platform, temperature control system, etc;
Control the start stop, sequential logic, and status feedback of each link to ensure synchronous execution of the process.
Fieldbus or Backplane Communication Interface
Communicate with the main controller (such as E244 series) through TEL dedicated bus protocol or industrial standard communication methods (such as CAN, RS-485, TTL, etc.);
The interface signal standard supports multiple levels: 24V/TTL/OC, etc.
Security and status monitoring
Cooperate with the system for fault detection, emergency shutdown linkage, safety interlock and other control logic;
Can be configured as a redundant circuit or an automatic reset control circuit to improve equipment safety and reliability.
2.产 品 展 示
