Tokyo Electron F18-623007-2超声波模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
一、基本信息
产品型号：F18-623007-2
产品名称：超声波模块（Ultrasonic Module）
制造商：Tokyo Electron Ltd.（东京电子）
模块类型：超声波传感与测量模块
应用领域：用于半导体制造设备中液位检测、距离测量、物位监控等。
二、功能定位
超声波信号发射与接收
发送超声波信号并接收其反射波，用于测量目标物体的位置或液体的液位高度。
信号处理
将接收到的超声波信号转换为电信号，经过滤波和放大后输出数字或模拟测量结果。
距离与液位测量
通过测量超声波传播时间来计算距离，实现精确液位或距离监控。
安全与防护
具备抗干扰能力，适应洁净室等特殊工作环境。
三、应用领域
液体槽液位检测
用于化学品槽、清洗槽、废液槽等液位实时监控。
设备内距离测量
监测机械部件、传送带、物料位置等。
防碰撞与物体检测
设备内部或自动化系统中物体接近检测。
英文资料：
1、 Basic Information
Product model: F18-623007-2
Product Name: Ultrasonic Module
Manufacturer: Tokyo Electron Ltd
Module type: Ultrasonic sensing and measurement module
Application areas: Used for liquid level detection, distance measurement, level monitoring, etc. in semiconductor manufacturing equipment.
2、 Functional positioning
Ultrasonic signal transmission and reception
Send ultrasonic signals and receive their reflected waves for measuring the position of target objects or the liquid level height of liquids.
Signal Processing
Convert the received ultrasonic signal into an electrical signal, filter and amplify it, and output digital or analog measurement results.
Distance and liquid level measurement
By measuring the propagation time of ultrasonic waves to calculate distance, precise liquid level or distance monitoring can be achieved.
Safety and Protection
Capable of anti-interference and adapting to special working environments such as clean rooms.
3、 Application Fields
Liquid tank level detection
Used for real-time monitoring of liquid levels in chemical tanks, cleaning tanks, waste liquid tanks, etc.
Distance measurement within the device
Monitor mechanical components, conveyor belts, material positions, etc.
Anti collision and object detection
Object proximity detection within equipment or automation systems.
2.产 品 展 示
