TEL Tokyo Electron 3281-000080-12电源分配板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
产品型号：3281-000080-12
产品名称：电源分配板（Power Distribution Board）
制造商：Tokyo Electron Ltd.（TEL）
部件类别：电源管理模块 / 电源分配模块
一、产品概述：
3281-000080-12 电源分配板 是TEL半导体设备中的关键电源管理部件，负责将输入电源合理分配到设备的各个子模块或组件，保证各部分获得稳定且合适的电压和电流供应。
该板具备多路电源输出和保护功能，确保设备安全稳定运行，同时防止电源异常导致的设备损坏。
二、主要功能：
| 功能模块 | 说明 |
|---|---|
| 电源分配 | 将主电源输入分配至多个输出端口，供给不同模块 |
| 过载保护 | 具备短路保护、过流保护，防止电源异常 |
| 电压调节 | 维持输出电压稳定，避免电压波动影响设备性能 |
| 状态监测 | 支持电源状态监测和报警信号输出 |
| 连接接口 | 多种电源输入输出接口，便于连接和维护 |
三、技术参数（基于TEL电源分配板通用规格推测）：
| 项目 | 参数说明 |
|---|---|
| 输入电压 | 通常为24V DC或其他工业标准电压 |
| 输出电压 | 多路输出，常见为5V、12V、24V DC |
| 最大输出电流 | 依据模块设计，典型数安培至十几安培 |
| 保护机制 | 短路保护、过载保护、过温保护 |
| 接口形式 | 螺丝端子、插拔式连接器等 |
| 尺寸与安装方式 | 适配TEL机柜或设备内部固定安装 |
英文资料：
Product model: 3281-000080-12
Product Name: Power Distribution Board
Manufacturer: Tokyo Electron Ltd. (TEL)
Component Category: Power Management Module/Power Distribution Module
1、 Product Overview:
The 3281-000080-12 power distribution board is a critical power management component in TEL semiconductor equipment, responsible for distributing input power to various sub modules or components of the equipment in a reasonable manner, ensuring stable and appropriate voltage and current supply to each part.
This board has multiple power outputs and protection functions to ensure safe and stable operation of the equipment, while preventing equipment damage caused by abnormal power supply.
2、 Main functions:
Function module description
Power distribution distributes the main power input to multiple output ports to supply different modules
Overload protection has short-circuit protection and overcurrent protection to prevent power supply abnormalities
Voltage regulation maintains stable output voltage and avoids voltage fluctuations affecting equipment performance
State monitoring supports power status monitoring and alarm signal output
Multiple power input and output interfaces for easy connection and maintenance
3、 Technical parameters (based on the general specifications of TEL power distribution board):
Project parameter description
The input voltage is usually 24V DC or other industry standard voltage
Multi channel output voltage, commonly 5V, 12V, 24V DC
The maximum output current is based on module design, typically ranging from several amperes to over ten amperes
Protection mechanisms include short circuit protection, overload protection, and over temperature protection
Interface forms include screw terminals, plug-in connectors, etc
Size and installation method suitable for fixed installation inside TEL cabinets or equipment
2.产 品 展 示
