Product Name: Control Main Board Card

Product model: 1208-001151-11

Manufacturer: Tokyo Electron Ltd. (TEL)

Component Type: Main Control Circuit Board/Mainboard Control Module

1、 Product Overview:

1208-001151-11 is a control motherboard card used in TEL semiconductor equipment, whose core function is to serve as the central control processing platform for a subsystem or the entire machine in the equipment. It undertakes the main logical operations and management tasks including data processing, control instruction execution, signal communication, equipment linkage, etc.

This motherboard card is usually used as an upper control system or central module, working in conjunction with various input/output, drive, and power modules, and is a key component to ensure the normal operation of the equipment.

2、 Main functions:

Function module description

The central processing unit integrates an embedded CPU or control chip, responsible for executing control programs

Internal storage with non-volatile Flash memory or SRAM/EEPROM for parameter storage

Peripheral interfaces provide various connection interfaces such as I/O, communication ports, encoders/analog inputs, etc

Bus communication and external module communication (possibly using TEL proprietary communication protocol, RS232, EtherCAT, CAN, etc.)

Control program management loads TEL device control firmware to achieve process scheduling and subsystem synchronization control

3、 Technical parameters (based on commonly used TEL control motherboards):

Project content (possible specifications)

Working voltage 5V/12V/24V DC (supplied according to the system)

Communication port RS-232C, Ethernet, CAN, IO expansion interface

Control signal processing capability supports multi-channel DI/DO, AI/AO, PWM control, etc

Software supports TEL proprietary operating system or real-time embedded firmware

Installation form: plug-in card/backplane connection/screw fixed, installed in TEL control rack
