TEL Tokyo Electron 1181-000540-13限制板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
TEL Tokyo Electron 1181-000540-13 限制板（Limiter Board）是用于TEL半导体制造设备中的电子功能模块，主要承担信号限制、保护和电平控制等安全功能。该板卡通常集成在关键工艺系统中，保护主控制系统及敏感部件免受异常电压或信号干扰。
一、基本信息
产品名称：限制板 / 限流板
型号：1181-000540-13
制造商：Tokyo Electron Ltd. (TEL)
组件类型：印刷电路板（PCB）
功能类别：信号限制与保护类模块
二、主要功能
电压/电流限制
防止输入信号超过设定阈值，保护主控电路或敏感器件；
抑制突波、浪涌或外部干扰信号。
信号电平匹配
实现不同子系统之间的电气隔离与电平转换；
保证系统整体信号传输的稳定性与兼容性。
设备运行保护
在设备异常状态（如短路、过载）时自动中断或限制信号；
避免损坏核心控制模块或昂贵部件。
英文资料：
The TEL Tokyo Electron 1181-000540-13 limiter board is an electronic functional module used in TEL semiconductor manufacturing equipment, mainly responsible for safety functions such as signal limitation, protection, and level control. This board is usually integrated into critical process systems to protect the main control system and sensitive components from abnormal voltage or signal interference.
1、 Basic Information
Product Name: Limiting Plate/Current Limiting Plate
Model: 1181-000540-13
Manufacturer: Tokyo Electron Ltd. (TEL)
Component type: Printed Circuit Board (PCB)
Function category: Signal restriction and protection module
2、 Main functions
Voltage/current limitation
Prevent input signals from exceeding the set threshold and protect the main control circuit or sensitive components;
Suppress sudden waves, surges, or external interference signals.
Signal level matching
Implement electrical isolation and level conversion between different subsystems;
Ensure the stability and compatibility of the overall signal transmission of the system.
Equipment operation protection
Automatically interrupt or limit signals when the device is in an abnormal state (such as short circuit, overload);
Avoid damaging the core control module or expensive components.
2.产 品 展 示
