TEL Tokyo Electron 2981-600669-11端子块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
TEL Tokyo Electron 2981-600669-11 端子块简介
产品定义：
2981-600669-11 是一款用于 Tokyo Electron 半导体设备的端子块（Terminal Block），用于实现设备内部多芯线缆的电气连接、分配与组织，是信号与电源线路的中转接口。主要功能：
实现电源线或控制信号线的分接、连接、绝缘与固定，确保线路连接清晰、可靠、便于维护。适用设备类型：
常用于 TEL 的各类晶圆处理设备，包括 CVD、Etch、Track 系统等，布置于控制柜、电源区、配电板或信号接口板上。连接信号类型：
直流电源线（如 +24V、+12V）
控制线（开关量、传感器反馈）
接地线（FG、GND）
通讯线缆或屏蔽线端接（部分型号）
产品特点：
多通道接线位，排布整齐
带有清晰标识，便于快速查线
高绝缘耐压，适用于工业电气环境
可配合端子帽、护罩、导轨等附件安装使用
安装位置：
通常安装在控制柜内部导轨上，靠近控制板、电源板或外部接口线束集成区。典型应用场景：
电机驱动模块与控制器间电源/信号中转
传感器（如温度、气压）信号回传接点
电磁阀、继电器等设备供电分接点
设备门联锁、安全急停回路连接点
英文资料：
Introduction to TEL Tokyo Electron 2981-600669-11 Terminal Block
Product definition:
2981-600669-11 is a terminal block used for Tokyo Electron semiconductor equipment, which is used to achieve electrical connection, distribution, and organization of multi-core cables inside the equipment. It is a relay interface for signal and power lines.
Main functions:
Implement the tapping, connection, insulation, and fixation of power lines or control signal lines to ensure clear, reliable, and easy maintenance of the circuit connections.
Applicable device types:
Various wafer processing equipment commonly used in TEL, including CVD, Etch, Track systems, etc., are arranged on control cabinets, power supply areas, distribution boards, or signal interface boards.
Connection signal type:
DC power cord (such as+24V,+12V)
Control line (switch quantity, sensor feedback)
Grounding wire (FG, GND)
Termination of communication cables or shielded wires (some models)
Product features:
Multi channel wiring positions arranged neatly
Clearly labeled for quick line checking
High insulation and voltage resistance, suitable for industrial electrical environments
Can be installed and used in conjunction with accessories such as terminal caps, shields, rails, etc
Installation location:
Usually installed on the internal guide rails of the control cabinet, near the control board, power board, or external interface wiring harness integration area.
Typical application scenarios:
Power/signal transfer between motor drive module and controller
Sensor (such as temperature, air pressure) signal feedback contact
Power supply tap points for equipment such as solenoid valves and relays
Equipment door interlock, safety emergency stop circuit connection point
