TEL Tokyo Electron BX80-000222-11控制器机架 PDF资料
1.产 品 资 料 介 绍：
中文资料：
TEL Tokyo Electron BX80-000222-11 控制器机架简介
产品定义：
BX80-000222-11 是一款专用于东京电子（TEL）半导体设备中的控制器机架，用于集中安装和管理多个控制模块、电源板、接口板等电子组件。核心功能：
为控制系统提供结构支持、散热通道和电气连接平台，确保控制器、驱动器、I/O板等模块的有序布置与稳定运行。结构特点：
采用模块化框架结构，方便模块的插拔和更换
通常带有标准导轨、卡槽、线缆固定机构
带有风扇或风道设计，用于主动或被动散热
安装位置：
安装于TEL设备的电气控制区域，靠近主控系统，便于操作人员维护和接线管理。适用模块类型：
常用于安装主控制器、运动控制卡、电机驱动器、DC-DC模块、传感器接口板、电源保护模块等。适配设备类型：
广泛应用于 TEL 的晶圆处理设备，如 CVD（化学气相沉积）、Etch（蚀刻）、Clean Track（清洗/显影系统）、Load Port、EFEM 等。供电与接线支持：
内部集成有电源分配总线、电缆接插口、信号连接端子，简化布线与维护操作。
英文资料：
Introduction to TEL Tokyo Electron BX80-00022-21 Controller Rack
Product definition:
BX80-0002222-11 is a controller rack specifically designed for Tokyo Electronics (TEL) semiconductor equipment, used for centralized installation and management of multiple control modules, power boards, interface boards, and other electronic components.
Core functions:
Provide structural support, heat dissipation channels, and electrical connection platforms for the control system to ensure the orderly arrangement and stable operation of modules such as controllers, drivers, and I/O boards.
Structural features:
Adopting a modular framework structure, it facilitates the insertion, removal, and replacement of modules
Usually equipped with standard guide rails, card slots, and cable fixing mechanisms
Equipped with fan or duct design for active or passive heat dissipation
Installation location:
Installed in the electrical control area of TEL equipment, close to the main control system, for easy maintenance and wiring management by operators.
Applicable module types:
Commonly used for installing main controllers, motion control cards, motor drivers, DC-DC modules, sensor interface boards, power protection modules, etc.
Adaptation device type:
Widely used in TEL wafer processing equipment, such as CVD (chemical vapor deposition), Etch (etching), Clean Track (cleaning/developing system), Load Port, EFEM, etc.
Power supply and wiring support:
Internally integrated with power distribution bus, cable sockets, and signal connection terminals, simplifying wiring and maintenance operations.
