TEL Tokyo Electron 2981-600310-12直流转换器板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
TEL Tokyo Electron 2981-600310-12 直流转换器板简介
产品定义：
2981-600310-12 是一款直流-直流转换器板（DC-DC Converter Board），用于在TEL设备中将输入直流电压转换为设备内部其他所需电压等级，提供稳定的多路供电。主要功能：
将主电源输入（如24V DC）转换为其他电压输出（如±12V、+5V等），供给控制板、传感器、通信模块等内部电路使用。典型应用设备：
应用于 Tokyo Electron 的晶圆处理设备，如 CVD（化学气相沉积）、Etch（蚀刻）、Clean Track（清洗）、ALD（原子层沉积）等系统。供电目标模块：
为PLC控制板、接口板、IO模块、传感器单元、信号采集器等低电压设备提供稳定供电。产品特点：
多通道DC输出（可能有±12V、+5V等）
具备过压、过流、短路保护
高转换效率，发热量低
模块化板卡结构，便于安装与维护
安装位置：
一般安装于控制电源架或主控制柜内部，靠近主控电源输出区或IO分配板。应用场景：
精密控制系统中对不同逻辑电平需求的电路板供电
为光电传感器、显示屏、控制器等提供隔离电源
起到电源电压隔离、抑制干扰的作用，提高设备电气安全性
英文资料：
Introduction to TEL Tokyo Electron 2981-600310-12 DC Converter Board
Product definition:
2981-600310-12 is a DC-DC Converter Board used to convert input DC voltage into other required voltage levels within TEL devices, providing stable multi-channel power supply.
Main functions:
Convert the main power input (such as 24V DC) into other voltage outputs (such as ± 12V,+5V, etc.) for use in internal circuits such as control boards, sensors, and communication modules.
Typical application devices:
Applied to wafer processing equipment of Tokyo Electron, such as CVD (chemical vapor deposition), Etch (etching), Clean Track (cleaning), ALD (atomic layer deposition) and other systems.
Power supply target module:
Provide stable power supply for low-voltage devices such as PLC control boards, interface boards, IO modules, sensor units, signal collectors, etc.
Product features:
Multi channel DC output (may have ± 12V,+5V, etc.)
Equipped with overvoltage, overcurrent, and short-circuit protection
High conversion efficiency, low heat generation
Modular board structure for easy installation and maintenance
Installation location:
Generally installed inside the control power rack or main control cabinet, close to the main control power output area or IO distribution board.
Application scenarios:
Power supply for circuit boards with different logic level requirements in precision control systems
Provide isolated power supply for photoelectric sensors, display screens, controllers, etc
Plays a role in isolating power supply voltage, suppressing interference, and improving equipment electrical safety
2.产 品 展 示
