Novellus Systems 76-380346-01制动电路板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Novellus Systems 76-380346-01 制动电路板（Brake Circuit Board） 是专为 Novellus 半导体制造设备设计的一款关键电子模块，主要用于控制和管理机械系统中电机的制动功能，确保设备在停止或紧急情况下能够快速且安全地减速或停止，防止机械部件过冲或损坏。
一、产品基本信息
产品型号：76-380346-01
产品名称：制动电路板（Brake Circuit Board）
制造商：Novellus Systems（现为 Lam Research 旗下品牌）
主要用途：电机制动控制及保护
二、核心功能
| 功能点 | 描述 |
|---|---|
| 电机制动控制 | 实现直流或交流电机的制动功能，包括动态制动和机械制动控制。 |
| 快速减速 | 通过控制电机制动电流，实现设备运动部分的快速、安全停止。 |
| 制动状态监测 | 反馈制动执行状态，确保制动动作按预期完成。 |
| 保护功能 | 过流保护、短路保护等，防止制动电路及电机损坏。 |
| 接口兼容 | 与主控系统及电机驱动模块紧密配合，实现联动控制。 |
三、典型应用领域
运动平台与载台控制
在晶圆处理或检测过程中，确保运动平台准确停止，防止冲击损坏。机械手臂制动
在自动化搬运或定位过程中，实现机械手的精准停止。阀门或驱动装置安全制动
防止阀门在断电或紧急状态下发生意外动作。紧急停机系统
作为设备安全系统的一部分，快速响应紧急停机命令。
英文资料：
The Novellus Systems 76-380346-01 Brake Circuit Board is a critical electronic module designed specifically for Novellus semiconductor manufacturing equipment. It is primarily used to control and manage the braking function of motors in mechanical systems, ensuring that the equipment can quickly and safely decelerate or stop in the event of a stop or emergency, preventing mechanical components from overshoot or damage.
1、 Basic Product Information
Product model: 76-380346-01
Product Name: Brake Circuit Board
Manufacturer: Novellus Systems (now a brand under Lam Research)
Main purpose: Motor braking control and protection
2、 Core functions
Function point description
Motor braking control realizes the braking function of DC or AC motors, including dynamic braking and mechanical braking control.
Rapid deceleration is achieved by controlling the braking current of the motor to achieve rapid and safe stopping of the moving parts of the equipment.
Braking status monitoring provides feedback on the execution status of braking, ensuring that the braking action is completed as expected.
Protection functions include overcurrent protection, short circuit protection, etc., to prevent damage to the braking circuit and motor.
Interface compatibility is closely coordinated with the main control system and motor drive module to achieve linkage control.
3、 Typical application areas
Sports platform and carrier control
Ensure that the motion platform stops accurately during wafer processing or inspection to prevent impact damage.
Mechanical arm brake
Realize precise stopping of the robotic arm during automated handling or positioning processes.
Valve or driving device safety brake
Prevent accidental valve operation during power outages or emergency situations.
emergency shutdown system
As part of the device security system, respond quickly to emergency shutdown commands.
