PEPPERL+FUCHS 2082 安全屏障模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
PEPPERL+FUCHS 2082
类型：安全屏障模块
系列：PEPPERL+FUCHS 系列
制造商
PEPPERL+FUCHS – 提供自动化、传感技术及爆炸危险环境安全技术的全球领先公司。
产品概述
PEPPERL+FUCHS 2082 安全屏障模块 是一款高可靠性的工业安全设备，专为防爆环境中的信号传输设计。该模块可提供信号隔离功能，确保在危险环境下的电气设备和控制系统的安全运行。它将低电压、低功率信号与危险区中的高电压信号隔离，从而有效防止火花、短路等引起的爆炸或火灾事故。
PEPPERL+FUCHS 2082 模块通过高效的安全屏障设计，支持对 4-20mA 电流信号、数字信号以及其他控制信号的隔离与保护。此模块广泛应用于石油、天然气、化工、电力等行业中，确保设备在易燃易爆区域中的安全运行。
主要技术参数
| 项目 | 参数说明 |
|---|---|
| 模块类型 | 安全屏障模块 |
| 输入信号 | 4-20mA、电压信号、数字信号 |
| 输出信号 | 隔离后的信号输出 |
| 额定电压 | 24V DC |
| 最大输入电流 | 20 mA |
| 供电电压范围 | 24V DC ±20% |
| 隔离电压 | 最大 250V |
| 工作温度范围 | -20°C 至 +60°C |
| 环境适应性 | 防尘、防水，符合 IP20 或更高等级 |
| 认证标准 | ATEX、IECEx 防爆认证 |
| 尺寸 | 22.5mm x 114mm x 100mm（标准 DIN 导轨安装尺寸） |
| 连接方式 | 螺钉端子连接 |
英文资料：
PEPPERL+FUCHS 2082
Type: Security Barrier Module
Series: PEPPERL+FUCHS Series
manufacturer
PEPPERL+FUCHS - a global leading company providing automation, sensing technology, and explosion hazardous environment safety technology.
product overview
The PEPPERL+FUCHS 2082 safety barrier module is a highly reliable industrial safety equipment designed specifically for signal transmission in explosion-proof environments. This module can provide signal isolation function to ensure the safe operation of electrical equipment and control systems in hazardous environments. It isolates low voltage and low power signals from high voltage signals in hazardous areas, effectively preventing explosions or fire accidents caused by sparks, short circuits, etc.
The PEPPERL+FUCHS 2082 module supports isolation and protection of 4-20mA current signals, digital signals, and other control signals through efficient safety barrier design. This module is widely used in industries such as petroleum, natural gas, chemical, and power to ensure the safe operation of equipment in flammable and explosive areas.
Main technical parameters
Project parameter description
Module Type: Safety Barrier Module
Input signal 4-20mA, voltage signal, digital signal
Output signal isolated signal output
Rated voltage 24V DC
Maximum input current 20 mA
Power supply voltage range 24V DC ± 20%
The maximum isolation voltage is 250V
Working temperature range -20 ° C to+60 ° C
Environmental adaptability: dustproof and waterproof, compliant with IP20 or higher levels
Certification standards ATEX, IECEx explosion-proof certification
Dimensions 22.5mm x 114mm x 100mm (standard DIN rail mounting dimensions)
Connection method: Screw terminal connection
2.产 品 展 示
