GE 193X543ADG02继电器卡 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GE 193X543ADG02 是通用电气（General Electric）193X 系列中的一款多路继电器输出卡，主要应用于工业自动化系统、驱动控制系统中，用于完成电路切换、信号联动、报警触发、执行控制等任务。该模块通过接收来自主控制单元的指令，驱动多个电磁继电器，实现不同控制逻辑下的通断动作。
该模块广泛用于 GE 的 DC/AC 驱动系统以及早期 Mark 系列控制系统，适合于工业设备启停、故障保护、顺序控制等场景。
技术参数与功能特点
产品型号：193X543ADG02
产品名称：继电器卡 / Relay Card
功能类型：电路开关控制、状态切换、报警输出等
通道数：一般包含 4~8 路独立控制的继电器（具体视实际版本而定）
触点类型：常开（NO）/常闭（NC）干接点输出
线圈驱动电压：24V DC 或 ±15V DC（由系统供电）
触点额定负载：约 1~2A @ 250V AC 或 30V DC（取决于继电器规格）
响应时间：典型 10~20ms
控制方式：板载逻辑接口由主板控制，自动或程序触发动作
接口形式：金手指连接器（用于插入 GE 控制框架背板）
板载保护电路：带有续流二极管、防反接保护、电压钳位等电路
显示功能：部分版本带有 LED 指示灯，反映每路继电器当前状态
工作温度范围：-20°C ~ +70°C
尺寸：标准 193X 系列控制板尺寸，可热插拔或模块替换
功能应用
实现控制系统中的逻辑开关动作
控制电机启停、风扇、泵或其他执行设备
系统报警联动触发（声光报警器、断电保护）
设备运行状态切换（工作/待机/故障）
用于安全控制系统的隔离触点输出
英文资料：
GE 193X543ADG02 is a multi-channel relay output card in the General Electric 193X series, mainly used in industrial automation systems and drive control systems to complete tasks such as circuit switching, signal linkage, alarm triggering, and execution control. This module drives multiple electromagnetic relays by receiving instructions from the main control unit, achieving on-off actions under different control logics.
This module is widely used in GE's DC/AC drive systems and early Mark series control systems, suitable for industrial equipment start stop, fault protection, sequence control and other scenarios.
Technical parameters and functional characteristics
Product model: 193X543ADG02
Product Name: Relay Card
Function type: Circuit switch control, status switching, alarm output, etc
Number of channels: generally includes 4-8 independently controlled relays (depending on the actual version)
Contact type: normally open (NO)/normally closed (NC) dry contact output
Coil driving voltage: 24V DC or ± 15V DC (powered by the system)
Contact rated load: approximately 1~2A @ 250V AC or 30V DC (depending on relay specifications)
Response time: Typical 10-20ms
Control mode: The onboard logic interface is controlled by the motherboard and triggers actions automatically or through a program
Interface form: Gold finger connector (used for inserting into GE control frame backplane)
Onboard protection circuit: equipped with freewheeling diode, anti reverse protection, voltage clamp and other circuits
Display function: Some versions come with LED indicator lights that reflect the current status of each relay
Working temperature range: -20 ° C~+70 ° C
Size: Standard 193X series control board size, hot swappable or module replaceable
Functional application
Implement logical switch actions in the control system
Control the start stop of motors, fans, pumps, or other executing devices
System alarm linkage triggering (sound and light alarm, power-off protection)
Equipment operation status switching (working/standby/fault)
Isolation contact output for safety control systems
2.产 品 展 示
